Phoenix Contact · Connection Cable
2302133 is a Phoenix Contact connection cable with Rated current Ie up to 4 A; Enclosure rating IP67 (IEC 60529); Operating temperature -25...+80 °C (IEC 60068-2-1). It is used in control panels, machine builds, spare-part replacements where the installed unit is matched to the original catalog number and a compact, documented part is required.
| Electrical | |
| Rated current Ie | up to 4 A |
|---|---|
| Rated torque | 0.2 Nm |
| I/O and communication | |
| Flame detection | IEC 60332-1-2 (raw cable) |
| Mechanical | |
| Weight | 231.8 g |
| Terminal wire size | Assembled shielded round cable |
| Enclosure rating | IP67 (IEC 60529) |
| Environment and compliance | |
| Operating temperature | -25...+80 °C (IEC 60068-2-1) |
| Certifications | CE, UL, cULus |
| Degree of protection | ≥ IP54 (Installation location) |
Values follow the Phoenix Contact Connection Cable specification for this catalog number; parameters not confirmed for this variant are omitted rather than estimated.
| Phoenix Contact Connection Cable variants | |||
| Catalog number | Rated current Ie | ||
|---|---|---|---|
| 2302133 (this page) | up to 4 A | ||
| 2302104 | up to 4 A | ||
| 2302120 | up to 4 A | ||
| 2302159 | up to 4 A | ||
Before selecting an alternative, confirm its dimensions, terminals and installation requirements in the manufacturer documentation.
The 2302133 is the device-level element in a Phoenix Contact connection cable installation. It receives the field signals and control supply listed above — the rated supply — and switches or conditions the load within the up to 4 A ratings shown in the Specifications table. Wiring and protective devices are sized to those same numbers, not to a generic assumption.
Typical installations place it in control panels, machine builds, spare-part replacements, where the unit is matched to the original catalog number and the enclosure provides standard panel or DIN-rail support. Record the catalog number and revision from the nameplate of the installed unit before specifying a like-for-like spare.
Phoenix Contact 2302133 — Industrial automation component supplied as a like-for-like replacement, selected by catalog number and published ratings. The figures below are taken from the specification table on this page for catalog number 2302133; verify the catalog number against your bill of materials before requesting a quotation.
Available from stock with datasheet, certificates and a quotation on request.
Q.Where can I find the rated torque data for 2302133?
It is listed in the specification table for Phoenix Contact 2302133 as 0.2 Nm. Use the value as the reference when sourcing a current-production equivalent.
Q.For 2302133, what does the specification table state about enclosure rating?
The specification table lists enclosure rating = IP67 (IEC 60529) for Phoenix Contact 2302133. Check the revision of the installed unit if the catalog number has been superseded.
Q.Which value is published under flame detection for catalog number 2302133?
For 2302133, flame detection is given as IEC 60332-1-2 (raw cable). Compare it with the nameplate of the installed unit before ordering.
Q.What should I include in an enquiry for 2302133?
Send the full catalog number 2302133, the required quantity and a photo of the nameplate. Stock, lead time and the applicable compliance documents can then be confirmed for Phoenix Contact 2302133.
Q.Can the 2302133 replace the unit currently installed in my panel?
Compare catalog number 2302133 and the ratings above with the nameplate of the installed device. A current-production equivalent is selected by function and electrical rating, not by the label alone.
