Allen-Bradley

Allen-Bradley 1762-IT4 | Relay & Timer

SKU: 1762-IT4
(2)
$331.00
In stock
Usually ships within 24 hours
Factory pre-tested, ready for instant commissioning！

All industrial automation equipment comes complete with standard matching accessories and detailed step-by-step commissioning manuals. Unbox, install and commission your automation projects smoothly with full confidence.

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

Email +86 18017464056

MicroLogix 4 Point Input Module

1762 MicroLogix 1200 System, 4 Channel, Thermocouple/Mv Module

Specifications

  • Class: Progmable Logic Controller
  • Depth: 87
  • Height: 90
  • I/O Isolation: Isolated
  • I/O Status Indication: LED
  • Number Of Channels: 4 point
  • Temperature Rating: 0¡­55 ¡ãC (32¡­131 ¡ãF)
  • Thermocouple Type: 4 Channel, Thermocouple/Mv Module
  • Accuracy: Thermocouple T: (-270...230 ¡ãC), without autocalibration ¡À0.3500 ¡ãC/¡ãC with temperature drift, maximum @ 0...60 ¡ãC ambient
  • A/D converter type: Delta-Sigma
  • Analogue inputs configurable: true
  • Analogue outputs configurable: false
  • Bus current draw: 50mA @ 24V DC, maximum
  • Cable impedance, max: 25
  • Calibration: The module performs autocalibration upon power-up and whenever a channel is enabled. You can also prog the module to calibrate every five minutes
  • Channel diagnostics: Over or under range or open circuit condition by bit reporting for analog inputs
  • CJC accuracy: ¡À1.3 ¡ãC
  • Common mode rejection: >110 dB at 60 Hz (with 10 or 60 Hz filter)
  • Common mode voltage range: ¡À10V
  • Conducted immunity: IEC 1000-4-6: 10V @ 0.15...80MHz
  • ESD immunity: IEC1000-4-2: 4kV contact, 8kV air, 4kV indirect
  • Fast transient burst: IEC1000-4-4 2kV @ 5kHz
  • Hazardous environment class: Class I, Division 2, Hazardous Location, Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213)
  • Heat dissipation: 1.5 total W (the W per point, plus the minimum W, with all points enabled)
  • Input and output group to system isolation: 30V AC/30V DC working voltage type test: 500V AC or 707V DC @ 1min
  • Input channel configuration: Via configuration software screen or the user prog (by writing a unique bit pattern into the module¡¯s configuration file)
  • Input, current: false
  • Input group to bus isolation: 30V AC/30V DC working voltage type test: 720V DC @ 1min
  • Input impedance: >10 M?
  • Input, resistance thermometer: false
  • Input, resistor: false
  • Input signal, configurable: true
  • Input, thermocouple: true
  • Input, voltage: false
  • Module OK LED: ON: module has power, has passed internal diagnostics, and is communicating over the bus, OFF: Any of the above is not true.
  • Module power LED: ON: indicates power is applied
  • Normal mode rejection ratio: 85 dB min @ 60 Hz with the 10 or 60 Hz filter selected
  • Number of analogue outputs: 4
  • Open-circuit detection time: 7 ms
  • Operating altitude: 2000 m
  • Operating humidity: 5...95% noncondensing
  • Operating temperature: -20 ¡ãC
  • Output, current: false
  • Output signal configurable: false
  • Output, voltage: false
  • Overload at input terminals: Maximum @ ¡À35V DC continuous
  • Radiated and conducted emissions: EN50081-2: Class A
  • Radiated immunity: IEC 61000-4-3: 10 V/m, 80...1000 MHz, 80% Alitude modulation, +900 MHz keyed carrier
  • Rated working voltage: 30V DC
  • Recommended cable: Belden? 8761 (shielded), shielded thermocouple extension wire for the specific type of thermocouple you are using. Follow thermocouple manufacturer¡¯s recommendations
  • Repeatability: Thermocouple T: ¡À1.5 ¡ãC for 10 Hz filter
  • Resolution: 15 bit plus sign
  • Response speed per channel: Input filter and configuration dependent
  • Shipping weight: 220 g
  • Shock: Relay ops: 7.5 G panel mounted (5 G DIN rail mounted)
  • Storage temperature: -40 ¡ãC
  • Suitable for safety functions: false
  • Surge immunity: IEC1000-4-5: 1kV galvanic gun
  • Type of electric connection: Screw connection
  • Vibration: Relay ops: 2 G
  • Width: 40 mm
