Allen-Bradley 1762-IQ32T | Relay & Timer

MicroLogix 32 Point Digital Input Module

1762 MicroLogix 1200 System, 32 Point 24 VDC Sink/Source Input Module

Specifications

• Class: Progmable Logic Controller
• Consist Of: Connectors
• Depth: 87
• digital input modules: 32 Point 24V DC Sink/Source
• Height: 90
• I/O Isolation: Isolated
• I/O Status Indication: LED
• Module Interfaces: digital input
• Number Of Channels: 32 point
• Special Features: sink - source
• Temperature Rating: -20¡­60 ¡ãC (-4¡­140 ¡ãF)
• Altitude: 2000 m
• Bus current draw, max: 170mA @ 5V DC
• Conducted RF immunity: IEC61000-4-6: 10V @ 0.15...80MHz
• Digital inputs configurable: false
• Digital outputs configurable: false
• EFT/B immunity: IEC61000-4-4: 2kV @ 5kHz on signal ports
• ESD immunity: EN 61000-4-2, 4 kV contact, 8 kV air, 4 kV indirect
• Hazardous environment class: Hazardous Location, Class I, Division 2 Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213, ANSI/ISA-12.12.01)
• Heat dissipation, max: 6.8 W @ 30.0V
• IEC input compatibility: Type 1
• Input group to backplane isolation: Verified by one of the following dielectric tests: 1200V AC @ 2s or 1697V DC @ 2s 75V DC working voltage (IEC Class 2 reinforced insulation)
• Isolated groups: Group 1: Inputs 0...7, Group 2 : Inputs 8...15, Group 3 : Inputs 16...23, Group 4 : Inputs 24...31
• Nominal Impedance: 4.7 k?
• Number of commons: 4
• Number of digital inputs: 32
• Off-state current, max: 1 mA
• Off-state voltage, max: 5V DC
• ON-state current, max: 6.5mA @ 30.0V DC
• On-state current, min: 2mA @ 15V DC
• On-state voltage, min: 10V DC
• Operating humidity: 5...95% noncondensing
• Operating temperature: -20 to 65 ¡ãC
• Operating voltage: 10¡­30V DC (24 points) @ 30 ¡ãC (86 ¡ãF) 10¡­26.4V DC (23 points) @ 60 ¡ãC (140 ¡ãF)
• Power supply distance rating: 6 (the module may not be more than 6 modules away from the system power supply)
• Radiated and conducted emissions: EN50081-2: Class A
• Radiated RF immunity: IEC61000-4-3: 10V/m, 80¡­2700 MHz, 80% Alitude modulation
• Redundancy: false
• Shock: Operating: 30G panel mounted, 3 pulses per axis, Relay ops: 7G
• Short-circuit protection, outputs available: false
• Signal delay: On delay: 8.0 ms
• Storage temperature, min: -40 ¡ãC
• Suitable for safety functions: false
• Surge transient immunity: IEC61000-4-5: 2 kV common mode, 1 kV differential mode
• Time delay at signal exchange: 8 ms
• Type of electric connection: Screw connection
• Type of voltage (input voltage): DC
• Vibration: Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak, 2 hr per axis Relay ops : 1.5G
• Voltage category: 24V DC sink/source
• Weight: 200 g
• Width: 40.4 mm
