Allen-Bradley 1762-IQ8OW6 | Relay & Timer

MicroLogix 14 Point Digital Comb Module

1762 MicroLogix 1200 System, 8 Point 24 VDC Sink/Source Input/6 Point VAC/VDC Relay Output Combination Module

Specifications

• Class: Progmable Logic Controller
• Depth: 87
• digital combination modules: 8 Point 24V DC Sink/Source Input/6 Point VAC/VDC Relay Output Combination Module
• Height: 90
• I/O Isolation: Isolated
• I/O Status Indication: LED
• Module Interfaces: digital
• Number Of Channels: 14 point
• Output: 6 Point, Relay
• Temperature Rating: -20¡­65 ¡ãC (-4¡­149 ¡ãF)
• Altitude: 2000 m
• Bus current draw, max: 80mA @ 24V DC
• Conducted RF immunity: IEC 1000-4-6: 10V @ 0.15...80MHz
• Digital inputs configurable: false
• Digital outputs configurable: false
• EFT/B immunity: IEC1000-4-4: 2kV @ 5kHz
• ESD immunity: IEC1000-4-2: 4kV contact, 8kV air, 4kV indirect
• Hazardous environment class: Class I, Division 2, Hazardous Location, Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213)
• Heat dissipation, max: 5.0 W @ 30V DC
• IEC input compatibility: Type 1+
• Input group to backplane isolation: Verified by one of the following dielectric tests: 1200V AC @ 1s or 1697V DC @ 1s 75V DC working voltage (IEC Class 2 reinforced insulation)
• Inrush current, max: 250 mA
• Isolated groups: Group 1: inputs 0...3, Group 2: inputs 4¡­7, Group 3: output 0...5
• Nominal Impedance: 3 k?
• Number of commons: Input : 2, output : 1
• Number of digital inputs: 8
• Off-state current: 1.5 mA
• Off-state leakage current, max: 0 mA
• Off-state voltage, max: 5V DC
• ON-state current, max: 12.0mA @ 30V DC
• On-state current, min: 2.0mA @ 10V DC
• On-state current, nom: 8.0mA @ 24V DC
• On-state voltage, min: 10V DC
• Operating humidity: 5...95% noncondensing
• Operating temperature: -20 to 65 ¡ãC
• Operating voltage: 10...30V DC @ 30¡ãC (86 ¡ãF) 10...26.4V DC @ 65¡ãC (149 ¡ãF)
• Power supply distance rating: 6 (the module may not be more than 6 modules away from the system power supply)
• Radiated and conducted emissions: EN50081-2: Class A
• Radiated RF immunity: IEC1000-4-3: 10 V/m, 80...1,000 MHz, 80% Alitude modulation, +900 MHz keyed carrier
• Redundancy: false
• Shock: Operating: 30G panel mounted, 3 pulses per axis Relay ops: 7G
• Short-circuit protection, outputs available: false
• Signal delay: On delay: 10.0 ms
• Storage temperature, min: -40 ¡ãC
• Suitable for safety functions: false
• Surge transient immunity: IEC1000-4-5: 2 kV common mode, 1 kV differential mode
• Time delay at signal exchange: 8 ms
• Type of electric connection: Screw connection
• Type of voltage (input voltage): DC
• Vibration: Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak, 2 hr per axis. Relay ops: 1.5G
• Voltage category: 24V DC sink/source
• Weight: 280 g
• Width: 40.4 mm
