Schneider Electric 140ACI03000 — technical reference listing by SHLY-PLC
The Schneider Electric 140ACI03000 is a tesys contactor supplied by SHLY-PLC as a tested spare and replacement component for industrial automation, electrical distribution and process-control systems. It is intended for maintenance, retrofit and urgent-breakdown orders; please confirm fitment against your machine, circuit diagram or existing part number before ordering.
| Product status | New - tested and inspected by SHLY-PLC |
|---|---|
| Manufacturer | Schneider Electric |
| Order number / SKU | 140ACI03000 |
| Product family / series | TeSys contactor |
| Range of product | Modicon Quantum automation platform |
| Product or component type | Analogue input module |
| Type of filter | Single pole low pass - 3 dB at 15 Hz +/- 20 % |
| Analogue input number | 8 |
| Input type | Differential |
| Addressing requirement | 9 input words |
| Analogue input resolution | 12 bits |
| Linear measuring range | 1...5 V; 4...20 mA |
| Absolute maximum input | 50 V DC; 25 mA |
| Input impedance | 250 Ohm current +/- 0.01 %; > 20 MOhm voltage |
| Absolute accuracy error | +/- 0.05 % of full scale; +/- 0.1 % of full scale maximum |
| Linearity error | +/- 0.04 % |
| Accuracy drift according to temperature | +/- 0.0025 % of full scale/°C; <= 0.005 % of full scale/°C |
| Common mode rejection | > - 72 dB 60 Hz |
| Isolation between channels and bus | 1000 V DC; 3000 V DC for 60 s |
| Isolation between channels | 30 V DC |
| Update time | 5 ms |
| Fault type | Broken wire 4...20 mA; Undervoltage range 1...5 V |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active); 1 LED (red) for external fault; 8 LEDs (green) for channel is turned on; 8 LEDs (red) for channel fault |
| Bus current requirement | 240 mA |
| Power dissipation in W | 2 W |
| Module format | Standard |
| Net weight | 0.3 kg |
| Approvals / standards | UL 508; CSA C22.2 No 142 |
| Product certifications | FM Class 1 Division 2; cUL |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2; 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…1000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.8 cm |
| Package 1 Width | 16.5 cm |
| Package 1 Length | 31.0 cm |
| Package 1 Weight | 450.0 g |
| Warranty (in months) | 18 |
Parameters compiled from the manufacturer's public product documentation. Full electrical ratings, dimensions and approvals are available on the official manufacturer datasheet or on request before ordering. 12-month seller warranty provided by SHLY-PLC.
To confirm fitment, share your machine model, tag number, circuit-diagram reference or existing device label. Cross-references are matched by function, electrical interface, rated current/voltage and mounting rather than by brand name alone.
