Keyence IV4-400MA — technical reference listing by SHLY-PLC
The Keyence IV4-400MA is a vision sensor & machine vision supplied by SHLY-PLC as a tested spare and replacement component for industrial automation, electrical distribution and process-control systems. It is intended for maintenance, retrofit and urgent-breakdown orders; please confirm fitment against your machine, circuit diagram or existing part number before ordering.
| Product status | New - tested and inspected by SHLY-PLC |
|---|---|
| Manufacturer | Keyence |
| Order number / SKU | IV4-400MA |
| Type | Narrow field of view model |
| Installed distance | From 400 mm 15.75" *1 |
| Available modes | Standard Mode, Sorting Mode, AI Through Count Mode |
| Tool with standard mode | Standard/Sorting Modes: AI Differentiate, Outline, ColorArea *2 , Area *3 , EdgePixels, ColorAverage *2 , Brightness Avg *3 , Width, Diameter, Edge Presence, Pitch, Color Prohibit, Position Adjustm... |
| Number of tools | 65 tools *4 |
| Field of view | Installation distance 400 mm 15.75" : 58 (H) × 44 (V) mm to Installation distance 3000 mm 118.11" : 464 (H) × 348 (V) mm (reference value) |
| Switch settings (programs) | 128 programs (with SD card)/32 programs (without SD card) |
| Focus adjustment | Auto *7 |
| Exposure time | 12 μs to 10 ms *8 |
| RUN display | Tool-specific list (judgment results, match, match bar display) *9 |
| RUN information | Switchable between OFF/histogram/processing time/count/output monitor Histogram: Histogram, match (MAX, MIN, AVG), OKs, NGs Processing time: Processing time (latest value, MAX, MIN, AVG), cap. time... |
| Illumination | Infrared LED |
| Lighting method | Pulse lighting |
| Tool functions | Additional Learning (AI Differentiate, AI Identify, AI OCR, AI Count, AI Trigger. AI Through Count Mode: Count), remove outline, masking function, color extraction/exclusion *2 , color histogram fu... |
| Utilities | List of NG sensor occurrences, NG hold, test run, I/O monitor, security settings (2-step password, Enhanced Security Mode), simulator *10 , adding FTP image information, multiple position adjustmen... |
| Indicators | OUT, TRIG, STATUS, LINK/ACT, SD |
| Digital inputs | 6, 3 of which are selectable between IN/OUT |
| Function | IN1: External trigger. IN2, IN3, I/O1 to I/O3: Assign any desired function. Assignable functions: Program switching, error clear, ext. master image registration, SD card save stop, OCR serial no. i... |
| Digital outputs | 6, 3 of which are selectable between IN/OUT |
| Connector | M12 12-pin A-code male connector |
| PoE | PoE Power Class 4/6 *12 |
| Standard | 1000BASE-T/100BASE-TX |
| Network function | FTP client, SFTP client, SNTP client, OPC UA server, MQTT client |
| Built-in Ethernet | EtherNet/IP, PROFINET CC-B *13 , TCP/IP Nonprocedural Comm (×2 connections) |
| Communication unit (IV4-CU1) | PROFINET CC-C *14 , EtherCAT® |
| Expanded memory | microSD card (microSD/microSDHC) *15 |
| Power voltage | 24 V +25%, -20% (including ripple) *16 |
| Power consumption | 3.4 A or less (at 19.2 V), 2.7 A or less (at 24.0 V)(no AI imaging illumination unit; with communication unit; includes 120 mA output load) 3.3 A or less (at 19.2 V), 2.6 A or less (at 24.0 V)(no A... |
| Average power consumption | 9.3 W (without AI imaging illumination unit) 12.8 W (with AI imaging illumination unit) |
| Enclosure rating | IP67 *18 |
| Ambient temperature | 0 to +50°C 32 to +122°F (no freezing) *19 |
| Relative humidity | 85% RH or less (no condensation) |
| Vibration resistance | Frequency: 10 to 500 Hz; Power spectral density: 0.816 G 2 /Hz; X, Y and Z directions *20 |
| Shock resistance | 500 m/s 2 1640.4 ft/s 2 3 times in each of 6 directions *20 |
| Material | Main unit case: Aluminum die-casting. Front cover: Acrylic (hard coating). Back plastic cover and plastic lid: PBT. Operation indicator cover: TPU. Power supply connector: PA/POM. Ethernet connecto... |
| Weight | Approx. 370 g 13.06 oz (no AI imaging illumination unit) Approx. 560 g 19.77 oz (with AI imaging illumination unit) |
Parameters compiled from the manufacturer's public product documentation. Full electrical ratings, dimensions and approvals are available on the official manufacturer datasheet or on request before ordering. 12-month seller warranty provided by SHLY-PLC.
To confirm fitment, share your machine model, tag number, circuit-diagram reference or existing device label. Cross-references are matched by function, electrical interface, rated current/voltage and mounting rather than by brand name alone.
