ABB

ABB S203-D25 Miniature Circuit Breaker 3P 25A D Curve

SKU: 2CDS253001R0251
(0)
$86.64
Only 10 units left
Condition
Free standard shipping on orders of $500 and above
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056
ABB S200 Series

S203-D25

Miniature Circuit Breaker — Triple Pole, 25A Rated

Current
25A
Poles
3P
Breaking
6kA
Order Code
2CDS253001R0251
Trip Curve
D curve
10-20× In instantaneous trip
Rated Voltage
230/400V AC

Application: High inrush currents, transformers. Ideal for 3p circuits requiring reliable overcurrent and short-circuit protection per IEC/EN 60898-1.

Technical Specifications
Series ABB S200
Model S203-D25
Order Code (SKU) 2CDS253001R0251
Number of Poles 3P
Rated Current (In) 25 A
Tripping Characteristic D curve — 10-20× In instantaneous trip
Rated Short-Circuit Breaking Capacity (Icn) 6kA at 230/400V
Rated Voltage (Ue) 230/400V AC
Reference Temperature 30 °C
Degree of Protection IP20 (installed) / IP40 (mounting)
Mounting DIN rail (TH35)
Electrical Life 4000 cycles
Mechanical Life 20000 cycles
Standard IEC/EN 60898-1
Operating Temperature -5 °C to +40 °C

Typical Applications

Large transformer inrush protection
Motor starting circuits
Welding equipment
X-ray machines

Key Features

  • Precision D-curve tripping for optimal circuit protection
  • 6kA short-circuit breaking capacity for reliable fault protection
  • Compact DIN rail mounting for efficient panel space utilization
  • Visually accessible trip indicator for quick status identification
  • Double insulation (Class II) for enhanced safety
  • Compatible with ABB accessory range (auxiliary contacts, shunt trips)

Compliance & Certifications

✓ IEC/EN 60898-1 ✓ CE Marked ✓ RoHS Compliant ✓ UL Listed (where applicable)

Order Code: 2CDS253001R0251 | Model: S203-D25
