The Tmax XT1C 160 is a compact molded case circuit breaker from ABB’s Tmax XT range, delivered as a fixed three-pole unit with front terminals and a thermomagnetic TMD release. It provides overcurrent and short-circuit protection for low-voltage distribution and motor circuits in a space-saving frame size.
This version is fitted with a TMD thermomagnetic release set at 100 A continuous current with magnetic trip at 1000 A, making it suited to feeder and sub-distribution protection up to the XT1 160 A frame rating. The fixed, front-connected configuration installs directly in panels and switchboards.
Tmax XT breakers combine high breaking capacity in a small footprint with a wide range of interchangeable accessories (auxiliary contacts, shunt releases, rotary handles) for flexible protection schemes in industrial and commercial installations.
| Product Series | ABB Tmax XT |
| Model | XT1C 160 TMD 100-1000 3p F F |
| Order Code | 1SDA067397R1 |
| EAN | 8015644012915 |
| Product Type | Molded Case Circuit Breaker (MCCB) |
| Number of Poles | 3P |
| Frame Current | 160 A |
| Release Type | Thermomagnetic TMD |
| Thermal Setting (In) | 100 A |
| Magnetic Setting | 1000 A |
| Mounting / Terminals | Fixed, front terminals (F F) |
| Dimensions (W x H x D) | 76.2 x 130 x 70 mm |
| Net Weight | 1.1 kg |
| Standards | IEC; UL/CSA available for the Tmax XT range |
| Brand | ABB |
| Condition | New Surplus |
| Warranty | 12-month warranty (provided by us) |
