WAGO 750-652 Serial Interface Module

SKU: 750-652
(0)
$190.88
Available
Condition
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056

The WAGO 750-652 is a serial interface module for industrial automation and control systems. It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.

Specifications

Technical parameters compiled from the manufacturer data sheet and reference documentation.

Key Specifications
Signal type RS-232
Transmission rate 300 Bd … 115.2 kBd
Bit transfer RS-485/-422: ISO 8482 / DIN 66259 - 4; RS-232: EIA/TIA-232-F
Transmission channels 1 TxD / 1 RxD, full-duplex, half-duplex
Line length RS-485/-422: approx. 1000 m (max.) twisted pair, RS-232: 40 m (max.)
Data width 1 x 46/1 x 22/1 x 6-byte input/output (parameterizable), 2-byte control/status
Parity None/Odd/Even
Number of data bits 7/8, adjustable
Type Designation
Order code 750-652
Product family / base order code 750
Version / revision suffix 652
Power Supply
Supply voltage (system) 5 VDC; via data contacts
Current consumption (system supply) 85mA
Supply voltage (field) 24 VDC; via power jumper contacts (power supply via blade contact; transmission (field side supply voltage only) via spring contact)
Number of incoming power jumper contacts 2
Number of outgoing power jumper contacts 2
Current carrying capacity (power jumper contacts) 10A
I/O & Signals
Transmission channels 1 TxD / 1 RxD, full-duplex, half-duplex
Connection technology: inputs / outputs 8 x CAGE CLAMP®
Mechanical & Environmental
Data width 1 x 46/1 x 22/1 x 6-byte input/output (parameterizable), 2-byte control/status
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 67.8 mm / 2.669 inches
Depth from upper-edge of DIN-rail 60.6 mm / 2.386 inches
Mounting type DIN-35 rail
Weight 49.8g
Ambient temperature (operation) 0 … +55 °C
Compliance, Approvals & Standards
Product approvals CE, UKCA, UL/cUL, RoHS
EMC EN 61000-6-x / EN 55011 (industrial environment)
Safety standard IEC/EN 61131 / 61800 / 60947 (product-specific)

Compatibility & Cross-References

  • Signal type: RS-232
  • Transmission rate: 300 Bd … 115.2 kBd
  • Transmission channels: 1 TxD / 1 RxD, full-duplex, half-duplex
  • Cross-references: send your existing part number or application and our technical team confirms fitment, protocol and wiring before you order.

Applications

  • The WAGO 750-652 is widely used to connect field I/O and serial devices to Ethernet and fieldbus control networks.
  • Typical uses include protocol linking, device-level data acquisition and SCADA/HMI integration.
  • It is deployed on conveyor lines, process skids and remote I/O stations where line topology reduces switching hardware.
  • Engineers also specify it for machine retrofits and as a network interface between legacy and modern controls.

Ordering, Delivery & Warranty

  • Availability: Worldwide shipping.
  • Delivery: Orders are processed within 2-4 business days after payment confirmation; worldwide delivery typically takes 5-8 business days, express service is available and shipping is free on orders over $500.
  • Condition & testing: Each unit is visually inspected and functionally checked before dispatch and packaged for protective international transit.

    • Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.

Independent supplier: WAGO part 750-652 is supplied by SHLY-PLC, an independent industrial-automation distributor. Brand names and part numbers are used for product identification and remain the property of their respective owners; this listing is not affiliated with, sponsored or endorsed by the manufacturer.

Frequently Asked Questions

Q: What condition is the 750-652 supplied in?

A: Each 750-652 is inspected and functionally checked before sale. Contact us for the current stock condition and quantity.

Q: How quickly can the 750-652 ship?

A: Orders are processed within 2-4 business days after payment confirmation. Standard worldwide delivery is about 5-8 business days, express shipping is available and orders over $500 ship free.

Q: Can you confirm compatibility or a replacement for the 750-652?

A: Yes. Share your existing part number or application and our technical team will verify compatibility and provide cross-references to comparable in-stock models.
