WAGO 750-1505 Digital Output Module

SKU: 750-1505
(0)
$68.86
Available
Condition
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056

The WAGO 750-1505 is a digital output module for industrial automation and control systems. It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.

Specifications

Technical parameters compiled from the manufacturer data sheet and reference documentation.

Key Specifications
Number of digital outputs 16
Number of Channels 16
Signal type Digital
Signal type (voltage) 24 VDC
Actuator connection 16 x (1-wire)
Output characteristic low-side switching
Output current per channel 0.5A
Output current short-circuit-protected
Type Designation
Order code 750-1505
Product family / base order code 750
Version / revision suffix 1505
Power Supply
Signal type (voltage) 24 VDC
Output current per channel 0.5A
Output current short-circuit-protected
Supply voltage (system) 5 VDC; via data contacts
Current consumption (system supply) 40mA
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission (field side supply voltage only) via spring contact)
Current consumption, field supply (module with no external load) 11mA
Number of incoming power jumper contacts 2
I/O & Signals
Number of digital outputs 16
Number of Channels 16
Output characteristic low-side switching
Output current per channel 0.5A
Output current short-circuit-protected
Output data width (internal) max. 16Bit
Connection technology: inputs / outputs 16 x Push-in CAGE CLAMP® (outputs)
Mechanical & Environmental
Output data width (internal) max. 16Bit
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69 mm / 2.717 inches
Depth from upper-edge of DIN-rail 61.8 mm / 2.433 inches
Mounting type DIN-35 rail
Weight 47.5g
Ambient temperature (operation) 0 … +55 °C
Compliance, Approvals & Standards
Product approvals CE, UKCA, UL/cUL, RoHS
EMC EN 61000-6-x / EN 55011 (industrial environment)
Safety standard IEC/EN 61131 / 61800 / 60947 (product-specific)

Compatibility & Cross-References

  • Signal type: Digital
  • Signal type (voltage): 24 VDC
  • Cross-references: send your existing part number or application and our technical team confirms fitment, protocol and wiring before you order.

Applications

  • The WAGO 750-1505 is used to switch control signals to actuators such as contactors, solenoid valves, indicators and motors.
  • It provides isolated, potential-free relay outputs for control cabinets and automation panels.
  • Typical applications include machine building, conveyor control and load switching in factory automation.
  • It is also fitted as a maintenance spare in installed WAGO 750/753 I/O installations.

Ordering, Delivery & Warranty

  • Availability: Worldwide shipping.
  • Delivery: Orders are processed within 2-4 business days after payment confirmation; worldwide delivery typically takes 5-8 business days, express service is available and shipping is free on orders over $500.
  • Condition & testing: Each unit is visually inspected and functionally checked before dispatch and packaged for protective international transit.

    • Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.

Independent supplier: WAGO part 750-1505 is supplied by SHLY-PLC, an independent industrial-automation distributor. Brand names and part numbers are used for product identification and remain the property of their respective owners; this listing is not affiliated with, sponsored or endorsed by the manufacturer.
