Schneider Electric · Smart Relay
SR2PACKFU is a Schneider Electric controller with Total I/O 10 (6 DI / 4 DO); Supply voltage 100…240 V AC; Enclosure rating IP20 (IEC 60529). It is used in packaging machines, conveyor transfer cells, small process skids where the installed unit is matched to the original catalog number and a compact, documented part is required.
| Electrical | |
| Rated insulation voltage Ui | 690 V (IEC 60947-4-1) |
|---|---|
| Rated impulse withstand Uimp | 6 kV (IEC 60947-4-1) |
| Supply voltage | 100…240 V AC |
| I/O and communication | |
| Total I/O | 10 (6 DI / 4 DO) |
| Mechanical | |
| Mounting | 35 mm DIN rail or screw fixing |
| Terminal type | Screw terminals |
| Enclosure rating | IP20 (IEC 60529) |
| Environment and compliance | |
| Operating temperature | -20…55 °C |
| Certifications | CE, UL, CSA, GL, GOST, C-Tick |
| Degree of protection | IP20 (terminal block), IP40 (front panel) conforming to IEC 60529 |
Values follow the Schneider Electric Smart Relay specification for this catalog number; parameters not confirmed for this variant are omitted rather than estimated.
| Schneider Electric Smart Relay variants | |||
| Catalog number | Total I/O | Supply voltage | |
|---|---|---|---|
| SR2PACKFU (this page) | 10 (6 DI / 4 DO) | 100…240 V AC | |
| SR2PACKBD | 10 (6 DI / 4 DO) | — | |
| SR2A101BD | 10 (6 DI / 4 DO) | — | |
| SR2A101FU | 10 (6 DI / 4 DO) | 100…240 V AC | |
Verify model-specific dimensions, terminals and installation requirements in the manufacturer documentation before selecting an alternative.
The SR2PACKFU is the device-level element in a Schneider Electric controller installation. It receives the field signals and control supply listed above — 100…240 V AC — and switches or conditions the load within the the rated ratings shown in the Specifications table. Wiring and protective devices are sized to those same numbers, not to a generic assumption.
Typical installations place it in packaging machines, conveyor transfer cells, small process skids, where the unit is matched to the original catalog number and the enclosure provides 35 mm DIN rail or screw fixing support. Record the catalog number and revision from the nameplate of the installed unit before specifying a like-for-like spare.
Schneider Electric SR2PACKFU Smart Relay Discovery Pack. See the manufacturer product information for this catalog number.
Cross-check the ratings above with the installed device before confirming the order.
Q.For SR2PACKFU, what does the specification table state about supply voltage?
The specification table lists supply voltage = 100…240 V AC for Schneider Electric SR2PACKFU. Check the revision of the installed unit if the catalog number has been superseded.
Q.Which value is published under rated insulation voltage Ui for catalog number SR2PACKFU?
For SR2PACKFU, rated insulation voltage Ui is given as 690 V (IEC 60947-4-1). Compare it with the nameplate of the installed unit before ordering.
Q.Before ordering SR2PACKFU, which operating temperature entry should be checked?
The operating temperature entry quoted above is -20…55 °C. Confirm this figure against the unit currently in the panel.
Q.How do I confirm compatibility of SR2PACKFU before ordering?
Match the catalog number SR2PACKFU and the specification values listed above against the installed unit, then confirm the firmware or hardware revision where a revision-sensitive part is involved.
Q.Can the SR2PACKFU replace the unit currently installed in my panel?
Compare catalog number SR2PACKFU and the ratings above with the nameplate of the installed device. A current-production equivalent is selected by function and electrical rating, not by the label alone.
