1FK2106-6AF1 — SIMOTICS S servomotor official specifications
1FK2106-6AF1
| Power / Supply | |
|---|---|
| DC link voltage | 600 V DC (for SINAMICS S120) |
| Feedback supply | Via DRIVE-CLiQ interface |
| Output / Load | |
|---|---|
| Rated speed | 2000 / 3000 / 4500 / 6000 rpm (model-specific) |
| Rated torque | 0.08…37 Nm (series range) |
| Rated power | 0.05…8.2 kW (series range) |
| Feedback | Absolute encoder 20-bit single-turn + 12-bit multi-turn (DRIVE-CLiQ, AM20DQI) |
|---|---|
| Cooling | Naturally cooled / external fan option |
| Mounting flange | IM B5 (IM V1 / V3); rotatable power connector |
| Compatibility | SINAMICS S120 / S110 / Drives 611 |
| Degree of protection | IP65 (standard) |
|---|---|
| Shaft | Round / keyed (model-specific) |
| Ambient temperature | 0…+40 °C |
| Operating temperature | −10 … +60 °C (model-specific derating above 40 °C) |
|---|---|
| Storage / transport | −40 … +70 °C |
| Relative humidity | Max. 95 %, non-condensing |
| Altitude | Up to 2000 m a.s.l. (derating above 1000 m) |
| Product approvals | CE, UKCA, UL/ULc, RoHS |
|---|---|
| EMC | EN 61000-6-x / EN 55011 (industrial environment) |
| Safety standard | IEC/EN 61131 / 61800 / 60947 (product-specific) |
| product_family | SIMOTICS S-1FK2 HD (high-dynamic) servo motor |
| stall_torque_M0_Nm | 16.0 |
| rated_torque_MN_Nm | 10.6 |
| rated_power_kW | 3.3 |
| rated_speed_rpm | 3000 |
| max_permissible_speed_rpm | 6000 |
| shaft | Cylindrical shaft D24 x 50 mm |
| degree_of_protection | IP64 |
| supply_voltage | 380-480 V (3AC) / 200-240 V |
Source: datasheet / product page
