Schneider Electric · ComPacT circuit breaker
LV426208 is a Schneider Electric circuit breaker with Rated current Ie 125 A; Rated operational voltage up to 690 V AC; Breaking capacity Icu/Ics 100% Icu. It is used in distribution boards, motor protection circuits, panel feeders where the installed unit is matched to the original catalog number and a compact, documented part is required.
| Electrical | |
| Rated current Ie | 125 A |
|---|---|
| Rated operational voltage | up to 690 V AC |
| Rated insulation voltage Ui | 750 V AC conforming to IEC 60947-2 |
| Rated impulse withstand Uimp | 8 kV conforming to IEC 60947-2 |
| Breaking capacity Icu/Ics | 100% Icu |
| Mechanical | |
| Weight | 1.06 kg |
| Mounting | By screws (plate) |
| Enclosure rating | IP40 conforming to IEC 60529 |
| Environment and compliance | |
| Operating temperature | -25...+70 °C |
| Certifications | CCC, CE, EAC, marine approvals |
| Degree of protection | IP40 |
Values follow the Schneider Electric ComPacT circuit breaker specification for this catalog number; parameters not confirmed for this variant are omitted rather than estimated.
| Schneider Electric ComPacT circuit breaker variants | |||
| Catalog number | Breaking capacity Icu/Ics | Rated operational voltage | |
|---|---|---|---|
| LV426208 (this page) | 100% Icu | up to 690 V AC | |
| LV426205 | 100% Icu | up to 690 V AC | |
| LV426206 | 100% Icu | up to 690 V AC | |
| LV426207 | 100% Icu | up to 690 V AC | |
Before selecting an alternative, confirm its dimensions, terminals and installation requirements in the manufacturer documentation.
The LV426208 is the device-level element in a Schneider Electric circuit breaker installation. It receives the field signals and control supply listed above — up to 690 V AC — and switches or conditions the load within the 125 A ratings shown in the Specifications table. Wiring and protective devices are sized to those same numbers, not to a generic assumption.
Typical installations place it in distribution boards, motor protection circuits, panel feeders, where the unit is matched to the original catalog number and the enclosure provides By screws (plate) support. Record the catalog number and revision from the nameplate of the installed unit before specifying a like-for-like spare.
Schneider Electric LV426208 — Circuit breaker providing branch-circuit overload and short-circuit protection in distribution boards and panel feeders. The figures below are taken from the specification table on this page for catalog number LV426208; confirm the installed unit's part number and revision so the replacement matches both electrically and mechanically.
Cross-check the ratings above with the installed device before confirming the order.
Q.Which value is published under rated current Ie for catalog number LV426208?
For LV426208, rated current Ie is given as 125 A. Compare it with the nameplate of the installed unit before ordering.
Q.Before ordering LV426208, which weight entry should be checked?
The weight entry quoted above is 1.06 kg. Confirm this figure against the unit currently in the panel.
Q.Where can I find the degree of protection data for LV426208?
It is listed in the specification table for Schneider Electric LV426208 as IP40. Use the value as the reference when sourcing a current-production equivalent.
Q.How do I confirm compatibility of LV426208 before ordering?
Match the catalog number LV426208 and the specification values listed above against the installed unit, then confirm the firmware or hardware revision where a revision-sensitive part is involved.
Q.Can the LV426208 replace the unit currently installed in my panel?
Compare catalog number LV426208 and the ratings above with the nameplate of the installed device. A current-production equivalent is selected by function and electrical rating, not by the label alone.
