Schneider Electric ATV320D15N4 VFD Drive

SKU: ATV320D15N4
(0)
$1,075.86
Available
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056

ATV320D15N4 Altivar Variable Speed Drive | Schneider Electric

The Schneider Electric ATV320D15N4 is an altivar variable speed drive. The listed technical data shows a supply of 380...500 V (- 15...10 %), communication via Modbus, based on the manufacturer's datasheet. It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.

Features

  • [Us] rated supply voltage: 380...500 V (- 15...10 %).
  • Communication port protocol: Modbus.
  • Motor power hp: 20 hp for heavy duty.
  • Degree of protection: UL type 1 with UL type 1 conformity kit.
  • Product weight: 8.8 kg.
  • Product certifications: EAC.

Specifications

Technical parameters compiled from the manufacturer data sheet and reference documentation.

Technical Specifications
Type Designation
Analogue input type Voltage (AI1) 0...10 V DC, impedance 30000 Ohm, resolution 10 bits
Connector type 1 RJ45 for Modbus/CANopen on front face
Product certifications EAC
Product weight 8.8 kg
Power Supply
[Us] rated supply voltage 380...500 V (- 15...10 %)
Apparent power 28.8 kVA at 500 V for heavy duty
Motor power hp 20 hp for heavy duty
Motor power kW 15 kW for heavy duty
Speed drive output frequency 0.1...599 Hz
Supply frequency 50...60 Hz (- 5...5 %)
Inputs & Outputs
Accuracy Analog input AI1, AI2, AI3 +/- 0.2 % for a temperature of -10...60 °C
Analog output AQ1 +/- 2 % for a temperature of -10...60 °C
Communication port protocol Modbus
Continuous output current 33 A at 4 kHz for heavy duty
Sampling duration Analog input (AI1, AI2, AI3) 2 ms
Communication & Interfaces
Communication module CANopen open style terminal block
Electrical connection Control, screw terminal 0.5...1.5 mm² AWG 20...AWG 16
Physical interface 2-wire RS 485 for Modbus
Mechanical
Degree of protection UL type 1 with UL type 1 conformity kit
Depth 232 mm
Height 330 mm
IP degree of protection IP20 conforming to EN/IEC 61800-5-1
Motor/Braking resistor, screw terminal 6...16 mm² AWG 8...AWG 6
Environmental
EMC filter Class C2 EMC filter integrated
Operating altitude <= 1000 m without derating
Pollution degree 2 conforming to EN/IEC 61800-5-1
Relative humidity 5...95 % without condensation conforming to IEC 60068-2-3
Shock resistance 15 gn during 11 ms conforming to EN/IEC 60068-2-27
Vibration resistance 1.5 mm peak to peak (f = 3...13 Hz) conforming to EN/IEC 60068-2-6
Compliance, Approvals & Standards
Insulation resistance > 1 mOhm at 500 V DC for 1 minute to earth
Standards EN/IEC 61800-3

Compatibility & Cross-References

Model variants, options and firmware revisions can affect fitment. Before ordering the Schneider Electric ATV320D15N4 altivar variable speed drive, share your existing part number or project requirements and our team will cross-reference comparable in-stock Schneider Electric units and verify compatibility. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for identification only.

Applications

  • Conveyor, fan and pump control where adjustable motor speed and energy savings are required.
  • Material-handling, packaging and processing machinery needing smooth acceleration and torque control.
  • Retrofits and spares for existing drive-controlled production lines and machine tools.
  • Industrial automation panels requiring reliable variable-speed motor operation.

Warranty

  • Availability: ATV320D15N4 is stocked for prompt shipment; contact us for current quantity and lead time.
  • Inspection & testing: each unit is visually inspected and functionally checked before packing.
  • Delivery: orders are processed within 2-4 business days after payment confirmation; standard worldwide delivery is about 5-8 business days, express shipping is available, and orders over $500 ship free.

    • Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
