The ProSoft PTQ-PDPMV1 is a industrial automation component for industrial automation and control systems. It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.
Technical parameters compiled from the manufacturer data sheet and reference documentation.
| Key Specifications | |
| Backplane Current Load | 1100 mA maximum @ 5 Vdc ± 5% |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% (with no condensation) |
| Vibration | Sine vibration 4-100 Hz in each of 3 orthogonal axes |
| Shock | 30 g, 11 mSec. in each of 3 orthogonal axes |
| Dimensions (HxWxD) | 250 x 103.85 x 40.34 mm (9.84 x 4.09 x 1.59 in) |
| PROFIBUS Baud Rate | Up to 12 Mbits/s, auto-baud detection |
| Type Designation | |
| Order code | PTQ-PDPMV1 |
| Product family / base order code | PTQ |
| Version / revision suffix | PDPMV1 |
| Power Supply | |
| Backplane Current Load | 1100 mA maximum @ 5 Vdc ± 5% |
| Ports & Interfaces | |
| PROFIBUS Interface | DPV1 RS-485, 9-pin D-shell female, optically isolated |
| Configuration Serial Port | DB-9M RS-232 only, no hardware handshaking |
| Configuration Ethernet Port | RJ45, link and activity LED |
| PROFIBUS PA Support | Via DP/PA coupler or link |
| Features & Performance | |
| PROFIBUS Baud Rate | Up to 12 Mbits/s, auto-baud detection |
| Max Slave Devices | Up to 125 with repeaters |
| Processor | Infineon C165 Microprocessor, Siemens ASIC ASPC2 Step E |
| Hot Standby Switchover | Nominal 100 ms, max 300 ms |
| Programming Software | Concept v2.6+, Unity Pro v2.2+, ProWORX v2.20+ |
| Mechanical & Environmental | |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% (with no condensation) |
| Vibration | Sine vibration 4-100 Hz in each of 3 orthogonal axes |
| Shock | 30 g, 11 mSec. in each of 3 orthogonal axes |
| Dimensions (HxWxD) | 250 x 103.85 x 40.34 mm (9.84 x 4.09 x 1.59 in) |
| Compliance | CE EMC-EN61326-1:2006; cULus Class I Div 2; CB IEC61010; ATEX Zone 2 |
| Compliance, Approvals & Standards | |
| Product approvals | CE, UKCA, UL/cUL, RoHS |
| EMC | EN 61000-6-x / EN 55011 (industrial environment) |
| Safety standard | IEC/EN 61131 / 61800 / 60947 (product-specific) |
