ProSoft Technology MVI94-GSC-E Communication Module

SKU: MVI94-GSC-E
(0)
$2,847.00
Available
Condition
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056

MVI94-GSC-E ProSoft Generic ASCII Serial Communication Module for Flex I/O

The ProSoft Technology MVI94-GSC-E is a Flex I/O backplane mounted generic ASCII serial communication module designed for Rockwell Automation Flex I/O system. It enables bidirectional ASCII serial data exchange between Flex I/O compatible controllers and serial field devices such as barcode scanners, weighing scales, serial printers and legacy ASCII instruments. Technical data sourced from official ProSoft datasheet. Supplied by SHLY-PLC, an independent industrial automation distributor; each unit undergoes visual inspection and functional testing before shipment for retrofit and spare replacement projects. Contact our team for compatibility verification.

Features

  • Order Code: MVI94-GSC-E
  • Product Family: MVI94 Flex I/O InRAx Series
  • Primary Function: Generic ASCII serial communication interface module for Rockwell Flex I/O backplane
  • Backplane: Flex I/O chassis mounting, compatible with Rockwell Flex I/O controllers
  • Serial Ports: Port1: RS232; Port2: jumper-selectable RS232/RS422/RS485, galvanic isolation
  • Serial Parameters: Baud rate 110 ~115200; data bits 5-8; parity None/Odd/Even/Mark/Space; stop bits 1 or 2
  • Data Handling: Configurable message termination by character, length or timeout; max 1023 bytes per message
  • Configuration: Config via mini DIN 8 RS232 debug port, ladder logic integration in RSLogix 500
  • LED Status: Application Status, Backplane Status, Port Tx/Rx diagnostic LEDs
  • Lifecycle: Discontinued OEM production, aftermarket spare part only
  • Typical Use: Connect barcode readers, weighing scales, serial printers, legacy ASCII serial instruments to Flex I/O PLC system

Specifications

Official Datasheet Technical Parameters

Technical Specifications
Catalog Number MVI94-GSC-E
Hardware Type Flex I/O Chassis Generic ASCII Serial Module
Backplane Power 800mA @ 5VDC, 3mA @ 24VDC
Serial Interface Port1 RS232; Port2 Jumper configurable RS232/422/485
Baud Rate Range 110 up to 115200 bps
Configuration Port Mini DIN 8 RS232 debug port
Environmental Ratings
Operating Temperature 0°C ~ +60°C (32°F ~ +140°F)
Storage Temperature -40°C ~ +85°C (-40°F ~ +185°F)
Relative Humidity 5% ~ 95% RH, Non-Condensing

Compatibility & Cross-References

The MVI94-GSC-E is ProSoft legacy serial ASCII module for Rockwell Flex I/O rack. It provides two serial ports to communicate with third-party ASCII serial devices, supporting fully customizable framing rules for start/stop characters and message timeout. Programming integration is completed in RSLogix 50 ladder logic. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for product identification only.

Applications

  • Flex I/O PLC connection to barcode scanners and stationary code readers
  • Industrial weighing scale, load cell ASCII data acquisition
  • Serial printer, alarm message printout, terminal emulation
  • Legacy ASCII serial instrument retrofit & spare replacement

Warranty

  • Availability: MVI94-GSC-E discontinued OEM production, supply as aftermarket spare; contact us for real-time stock status.
  • Inspection & testing: each unit is visually inspected and functionally checked before packing.
  • Delivery: orders are processed within 2-4 business days after payment confirmation; standard worldwide delivery is about 5-8 business days, express shipping available, orders over $500 ship free.

Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.

Independent supplier: ProSoft Technology part MVI94-GSC-E is supplied by SHLY-PLC, an independent industrial automation distributor. Brand names and part numbers are used for product identification and remain the property of their respective owners; this listing is not affiliated with, sponsored or endorsed by the manufacturer.

Frequently Asked Questions

Q: What is MVI94-GSC-E?

A: MVI94-GSC-E is ProSoft generic ASCII serial communication module for Rockwell Flex I/O backplane, used to connect ASCII serial field instruments to Flex I/O controllers.

Q: What serial signals are supported?

A> Port1 fixed RS232; Port2 jumper selectable RS232 / RS422 / RS485, supporting multi-drop 485 bus.

Q: What software is used for programming?

A: Configuration via debug port, logic programmed in RSLogix 50 for SLC / Flex I/O platform.
