The ProSoft Technology MVI69-DFNT is a single-slot 1769 backplane DF1 over Ethernet communication module for Rockwell CompactLogix PAC and MicroLogix 1500 LRP controllers. It implements DF1 protocol encapsulated over 10/100 Base-T Ethernet, enabling CompactLogix to communicate with legacy Allen‑Bradley PLC-5, SLC500 and other DF1-capable controllers across LAN/WAN networks. Technical data sourced directly from official ProSoft MVI69-DFNT datasheet & user manual. Supplied by SHLY-PLC, an independent industrial automation distributor; each unit undergoes visual inspection and functional testing before shipment for retrofit and spare replacement projects. Contact our team for compatibility verification.
Official Datasheet & User Manual Technical Parameters
| Technical Specifications | |
| Catalog Number | MVI69-DFNT |
| Hardware Type | 1769 Single-Slot DF1 over Ethernet Communication Module |
| Backplane Current Draw | 800mA @ 5.1 VDC |
| Power Supply Distance Rating | 2 |
| Ethernet | 10/100 Base-T, RJ45, 1500Vrms isolation from backplane |
| DF1 Mode | Full / Half duplex, CRC or BCC checksum selectable, Client & Server support |
| Configuration Debug Port | RJ45 RS232, supplied RJ45 to DB9M cable |
| Environmental Ratings | |
| Operating Temperature | 0°C ~ +60°C (32°F ~ +140°F) |
| Storage Temperature | -40°C ~ +85°C (-40°F ~ +185°F) |
| Relative Humidity | 5% ~ 95% RH, Non-Condensing |
| Agency Certifications | |
| cULus | UL508, UL1604, Class I Div 2 Groups A,B,C,D T6 |
| ATEX | II 3 G Ex nA IIC T6 X |
| Compliance | CE, RoHS |
The MVI69-DFNT is legacy DF1-over-Ethernet module for Rockwell 1769 CompactLogix / MicroLogix 1500 LRP rack. It appears as standard 1769 I/O module to PLC processor, uses AOI to map DF1 data between legacy controllers and CompactLogix tags. Not compatible with 1769-L23E-QBFC1B, 1769-L16x, 1769-L18x processors. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for product identification only.
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: MVI69-DFNT is ProSoft DF1 over Ethernet communication module for Rockwell 1769 CompactLogix / MicroLogix 1500 LRP backplane.
A: DF1 protocol encapsulated over 10/100 Ethernet, supports DF1 client and server, full/half duplex, CRC or BCC checksum options.
A: Legacy Allen‑Bradley PLC‑5, SLC 500 and other DF1 capable PLCs via Ethernet network.
A: 1769-L23E-QBFC1B, 1769-L16x and 1769-L18x controllers cannot work with MVI69-DFNT.
