The ProSoft Technology MVI69-ADM is a single-slot programmable application development module for Rockwell CompactLogix PAC and MicroLogix 1500 LRP controllers. It supports ANSI C custom programming for proprietary protocol conversion, serial data parsing and custom gateway functions, without built-in Ethernet port. Technical data sourced directly from official ProSoft MVI69-ADM datasheet & developer guide. Supplied by SHLY-PLC, an independent industrial automation distributor; each unit undergoes visual inspection and functional testing before shipment for retrofit and spare replacement projects. Contact our team for compatibility verification.
Official Datasheet & Developer Guide Technical Parameters
| Technical Specifications | |
| Catalog Number | MVI69-ADM |
| Hardware Type | 1769 Single-Slot Programmable C Application Module (Serial Only) |
| Backplane Current Draw | 800mA @ 5.1 VDC, 3mA @24VDC |
| Power Supply Distance Rating | 2 |
| Ethernet | Not equipped, no onboard RJ45 port |
| Serial Ports | 2 ports, jumper selectable RS232/RS422/RS485, fully controlled by custom C code |
| Programming Language | ANSI C, compiled user application firmware |
| Environmental Ratings | |
| Operating Temperature | 0°C ~ +60°C (32°F ~ +140°F) |
| Storage Temperature | -40°C ~ +85°C (-40°F ~ +185°F) |
| Relative Humidity | 5% ~ 95% RH, Non-Condensing |
| Agency Certifications | |
| cULus | UL508, UL1604, Class I Div 2 Groups A,B,C,D T6 |
| ATEX | II 3 G Ex nA IIC T6 X |
| Compliance | CE, RoHS |
The MVI69-ADM is legacy programmable application module for Rockwell 1769 CompactLogix / MicroLogix 1500 LRP rack. It appears as standard 1769 I/O module to PLC processor, AOI instructions handle data mapping between custom module application and CompactLogix controller tags. Not compatible with 1769-L23E-QBFC1B, 1769-L16x, 1769-L18x processors. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for product identification only.
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: MVI69-ADM is ProSoft programmable ANSI C application development module (serial only) for 1769 CompactLogix / MicroLogix1500 LRP, designed for custom serial protocol gateways.
A: Two configurable RS232/422/485 serial ports, no built-in Ethernet port.
A: MVI69-ADM is serial-only with dual serial ports, no Ethernet. MVI69-ADMNET is the upgraded variant with onboard 10/100 Ethernet RJ45 port.
A: 1769-L23E-QBFC1B, 1769-L16x and 1769-L18x controllers cannot be used with MVI69-ADM.
