The ProSoft ICX35-HWC-E is a industrial automation component for industrial automation and control systems. It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.
Technical parameters compiled from the manufacturer data sheet and reference documentation.
| Key Specifications | |
| Cellular Technology | LTE, GSM, UMTS/HSPA+, GPRS, EDGE, CDMA |
| Verizon Certified | ICX35-HWC-A |
| AT&T Certified | ICX35-HWC-A |
| PCTRB | ICX35-HWC-A and ICX35-HWC-E |
| Activation | SIM Slot |
| Security | OpenVPN client, IPSec client, IP Address Filtering |
| Enclosure | Extruded aluminum with DIN clip |
| Dimensions(H x W x D) | 5.52 x 2.06 x 4.37 in14.01 x 5.24 x 11.09 cm |
| Type Designation | |
| Order code | ICX35-HWC-E |
| Product family / base order code | ICX35 |
| Order code segment — model / options | HWC |
| Version / revision suffix | E |
| Power Supply | |
| External Power | 10 to 30 VDC |
| Peak Power Consumption | < 6W |
| Ports & Connections | |
| Ethernet Port | (1) 10/100 Base-T, RJ45 connector |
| Serial Port | (1) DB9 female (serial tunneling & encapsulation) |
| Antenna Ports | (2) Female RP-SMA connectorAntenna(s) sold separately |
| Mechanical & Environmental | |
| Enclosure | Extruded aluminum with DIN clip |
| Dimensions(H x W x D) | 5.52 x 2.06 x 4.37 in14.01 x 5.24 x 11.09 cm |
| Shock | IEC 60068-2-27; 20G @ 11ms (Operational)IEC 60068-2-27; 30G @ 11ms (Non-Operational) |
| Vibration | IEC 60068-2-6; 10G, 10 to 150 Hz |
| Weight | 14.5 oz (411 g) |
| Operating Temperature | IEC 60068 -40°F to +158°F (-40°C to +70°C) |
| Humidity | IEC 60068-30 5% to 95%, with no condensation |
| Compliance, Approvals & Standards | |
| Product approvals | CE, UKCA, UL/cUL, RoHS |
| EMC | EN 61000-6-x / EN 55011 (industrial environment) |
| Safety standard | IEC/EN 61131 / 61800 / 60947 (product-specific) |
