The ProSoft Technology 5102-MCM4-DFCM4 is an in-rack communication module designed for Allen‑Bradley PLC chassis. It provides 4 channels of Modbus Master/Slave and DF1 Master/Slave serial communication, supporting multi-drop industrial serial networks for factory automation and legacy PLC integration. Technical data sourced directly from official ProSoft 5102-MCM4-DFCM4 datasheet & user manual. Supplied by SHLY-PLC, an independent industrial automation distributor; each unit undergoes visual inspection and functional testing before shipment for retrofit and spare replacement projects. Contact our team for compatibility verification.
Official Datasheet & User Manual Technical Parameters
| Technical Specifications | |
| Catalog Number | 5102-MCM4-DFCM4 |
| Hardware Type | Rack Mount Serial Communication Module, 5100 Series |
| Serial Channels | 4 Isolated Serial Ports |
| Supported Protocols | Modbus RTU Master/Slave, DF1 Master/Slave |
| Serial Interfaces | RS232 / RS422 / RS485, software selectable per port |
| Configuration Tool | ProSoft Configuration Builder (PCB) |
| Mounting | Allen‑Bradley Chassis Rack Mount |
| Environmental Ratings | |
| Operating Temperature | 0°C ~ +60°C (32°F ~ +140°F) |
| Storage Temperature | -40°C ~ +85°C (-40°F ~ +185°F) |
| Relative Humidity | 5% ~ 95% RH, Non-Condensing |
| Agency Certifications | |
| cULus | UL508 |
| Compliance | CE, RoHS |
The 5102-MCM4-DFCM4 belongs to ProSoft 5100 series rack mounted communication module. It features four independent isolated serial ports, each can run Modbus RTU or DF1 protocol, Master or Slave. It plugs directly into Allen‑Bradley PLC chassis for integrating serial field devices. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for product identification only.
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: 5102-MCM4-DFCM4 is ProSoft 5100 series rack PLC module with 4 serial ports supporting Modbus RTU and DF1 protocols.
A: 4 isolated serial ports, each can independently select protocol and master/slave mode.
A: RS232, RS422, RS485, software selectable for each channel.
A: Powered by Allen‑Bradley PLC chassis backplane, no separate external DC supply required.
