ProSoft 5102-MCM-ASCII3 Multi-Channel ASCII / Modbus Master Module for ControlLogix

The ProSoft 5102-MCM-ASCII3 is a 1756 form factor communication module for Allen‑Bradley ControlLogix chassis. It provides three independent serial ports supporting Modbus RTU Master and ASCII protocol, enabling direct connection to serial instruments, weight scales, barcode readers and legacy serial devices.

Key Features

  • 1756 ControlLogix rack module, hot-swappable backplane connection
  • 3 independent serial channels (Channel 0,1,2)
  • Each channel configurable: Modbus RTU Master or ASCII protocol
  • Serial hardware selectable: RS232 / RS422 / RS485 per port
  • Supports ASCII string parsing, custom framing and trigger rules
  • Web diagnostic page, status LEDs, configuration via ProSoft Configuration Builder
  • Galvanic isolation on serial ports to reduce electrical noise interference

Technical Specifications

Part Number 5102-MCM-ASCII3
Product Type Multi-Channel Modbus RTU Master / ASCII Communication Module
Host Chassis Allen‑Bradley 1756 ControlLogix
Serial Channels 3 independent serial ports
Serial Interface RS232 / RS422 / RS485 (selectable per channel)
Supported Protocols Modbus RTU Master, ASCII
Baud Rate Range 110 ~ 115200 bps
Backplane Current Draw 700 mA @ 5.1 VDC
Operating Temperature 0°C ~ +60°C
Storage Temperature -40°C ~ +85°C
Humidity 5% ~ 95% non-condensing
Certifications UL, cUL, CE

Applications

Industrial serial data acquisition for ControlLogix systems. Connect weighing scales, barcode scanners, serial meters, analyzers and Modbus RTU field devices in food processing, packaging, material handling and process automation.
