ProSoft Technology 3170-PDP Communication Module

SKU: 3170-PDP
(0)
$1,329.00
Available
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056

3170-PDP ProSoft FLEX I/O PROFIBUS DP Slave Adapter Module

The ProSoft Technology 3170-PDP is a FLEX I/O PROFIBUS DP slave network interface adapter. It mounts directly on Rockwell FLEX I/O terminal base, acting as PROFIBUS DP Slave to connect FLEX I/O modules to PROFIBUS DP Master scanners. It collects input data from FLEX I/O backplane and outputs DP master commands to local FLEX I/O modules. Technical data sourced from official ProSoft datasheet. Supplied by SHLY-PLC, an independent industrial automation distributor; each unit undergoes visual inspection and functional testing before shipment for retrofit and spare replacement projects. Contact our team for compatibility verification.

Features

  • Order Code: 3170-PDP
  • Product Family: FLEX I/O Adapter Series
  • Primary Function: PROFIBUS DP Slave adapter for Rockwell FLEX I/O backplane
  • PROFIBUS Port: DB9 female connector, PROFIBUS DP V0 Slave
  • Backplane Interface: FLEX I/O backplane, works with standard FLEX I/O modules
  • Node Address: Thumbwheel switch setting, address range 01~99
  • GSD File: Official GSD file available for PROFIBUS master configuration
  • LED Status: Power, Module Status, PROFIBUS Bus Activity, Fault LED
  • Mounting: Installs on Rockwell FLEX I/O terminal base
  • Lifecycle: Discontinued OEM production, aftermarket spare part only
  • Typical Use: Factory automation, integrate Rockwell FLEX I/O into Siemens PROFIBUS DP master networks

Specifications

Official Datasheet Technical Parameters

Technical Specifications
Catalog Number 3170-PDP
Hardware Type FLEX I/O PROFIBUS DP Slave Adapter
Power Supply 24VDC nominal, range 18 ~ 30 VDC
Max Current Draw 200mA @ 24VDC
PROFIBUS Interface DB9 female, PROFIBUS DP V0 Slave
Supported I/O Backplane Rockwell Automation FLEX I/O & Integra I/O
Protocols Implemented PROFIBUS DP V0 Slave
Environmental Ratings
Operating Temperature 0°C ~ +60°C (32°F ~ 140°F)
Storage Temperature -40°C ~ +85°C (-40°F ~ +185°F)
Relative Humidity 5% ~ 95% RH, Non-Condensing

Compatibility & Cross-References

The 3170-PDP is ProSoft FLEX I/O PROFIBUS DP slave adapter. Compatible with all standard Rockwell FLEX I/O digital & analog modules, works with Siemens S7 and other PROFIBUS DP master scanners. Node address configurable via front thumbwheel switch, GSD file for integration in PROFIBUS configuration tools. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for product identification only.

Applications

  • Migrate Rockwell FLEX I/O into PROFIBUS DP automation systems
  • Siemens S7 PLC integration with Rockwell FLEX I/O field stations
  • Legacy system retrofit, reuse existing FLEX I/O wiring and modules
  • Industrial production line, material handling and process control I/O expansion

Warranty

  • Availability: 3170-PDP discontinued OEM production, supply as aftermarket spare; contact us for real-time stock status.
  • Inspection & testing: each unit is visually inspected and functionally checked before packing.
  • Delivery: orders are processed within 2-4 business days after payment confirmation; standard worldwide delivery is about 5-8 business days, express shipping available, orders over $500 ship free.

Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.

Independent supplier: ProSoft Technology part 3170-PDP is supplied by SHLY-PLC, an independent industrial automation distributor. Brand names and part numbers are used for product identification and remain the property of their respective owners; this listing is not affiliated with, sponsored or endorsed by the manufacturer.

Frequently Asked Questions

Q: What is 3170-PDP?

A: 3170-PDP is a ProSoft FLEX I/O PROFIBUS DP Slave adapter, connecting Rockwell FLEX I/O modules to PROFIBUS DP master controllers via PROFIBUS DP network.

Q: How to configure 3170-PDP?

A: Set PROFIBUS node address via front thumbwheel switch, import official GSD file in PROFIBUS master configuration software for I/O mapping.

Q: What power supply is required?

A: 18~30 VDC input, nominal 24VDC, max current draw 200mA @24VDC.
