Non-contact magnetic safety switch · 2 N/O reed · 8 mm · M8 4-pin · square · sensor only (1 switch)
The Pilz 524120 (PSEN 1.1p-20 / 8mm / 1switch) is the sensor-only version of the PSEN 1.1 square magnetic safety switch, using two normally-open reed safety contacts to monitor movable safety gates per EN ISO 14119 and EN 60947-5-3. Supplied as the switch head only, it connects via a 4-pin M8 connector and carries the IP67 sealed, ECOLAB-tested housing typical of the PSENmag family.
Supplied by SHLY-PLC, an independent industrial-automation distributor. Brand and model are used for identification only; this listing is not affiliated with, sponsored or endorsed by the manufacturer.
524120
| Sibling models | 504220 = PSEN 1.1p-20/PSEN 1.1-20/8mm/1unit (sensor + actuator) · 504223 = PSEN 1.1p-23 ATEX 1-unit |
|---|---|
| Required actuator | PSEN 1.1-20 square magnet (order no. 514120) |
| Scope of delivery | 1 safety switch head only; actuator and M8 cable ordered separately |
| Power supply | |
|---|---|
| Nominal supply voltage | 24 V DC |
| Voltage tolerance | -20 % / +20 % |
| Current consumption | ≤ 10 mA |
| Reverse-polarity protection | Yes |
| I/O & contacts | |
|---|---|
| Safety contacts | 2 x N/O (reed, potential-free) |
| Switching voltage | 24 V DC |
| Max. switching current | 0.5 A |
| Max. breaking capacity | 10 W |
| Connection | M8, 4-pin male connector |
| Performance level (PL) | Up to PL e (EN ISO 13849-1) |
|---|---|
| Category | Up to Category 4 |
| SIL / SIL CL | Up to SIL CL 3 (IEC 62061) |
| Classification (EN 60947-5-3) | PDDB |
| Coding level (EN ISO 14119) | Low coding |
|---|---|
| Switching principle | Non-contact magnetic (reed) |
| Housing material | Plastic |
| Evaluation device | Pilz PNOZ X / PNOZsigma / PNOZmulti |
| Design | Square, plastic housing |
|---|---|
| Dimensions sensor | 37 x 26.4 x 13 mm (approx.) |
| Mounting | 2 x M4 fixing screws |
| Degree of protection | IP65 / IP67 |
| Fixing torque | 0.8 Nm max. |
| Ambient temperature, operation | -25 … +55 °C |
|---|---|
| Vibration resistance | EN 60068-2-6 |
| Shock resistance | EN 60068-2-27 |
| Cleaning | ECOLAB tested |
| Housing material | PBT |
| Approvals / certifications | CE · EAC (Eurasian) · TÜV · cULus Listed · ECOLAB tested |
|---|---|
| Functional safety standards | EN ISO 13849-1 (PL e / Cat. 4) · IEC 62061 (SIL CL 3) · IEC 61508 · EN 60947-5-3 (PDDB) · EN ISO 14119 |
| EMC standards | EN 61000-6-2 (immunity) · EN 61000-6-3 (emission) |
| General standards | EN 60204-1 · EN ISO 12100 |
