Omron ZENL1121 Contactor

SKU: ZENL1121
(0)
$117.06
In stock (95 units)
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056

Omron ZENL1121 Accessory

The Omron ZENL1121 is part of the ZEN series programmable relay family — a cost-effective all-in-one alternative to multiple discrete control components. The ZEN series was discontinued by Omron in March 2024; new surplus stock is available from SHLY-PLC.

Key Features

  • Model: ZENL1121
  • Series: Omron ZEN programmable relay
  • Function: small-scale automatic control (timing, counting, relay logic)
  • Lifecycle: discontinued by Omron (March 2024); new surplus stock available

Technical Specifications

Omron ZEN series — reference data (source: fa.omron.co.jp)

Technical Specifications
Product Type ZEN series accessory / mounting kit
Use Mounting / accessory for ZEN programmable relay
Control Method Stored program method, cyclic scan
Programming Language Ladder diagram (via ZENSOFT PC software)
Program Capacity 96 lines (up to 3 input contacts + 1 output coil per line)
Maximum I/O Points Up to 44 points (20-point CPU: IN12 / OUT8 + up to 3 expansion units IN4/OUT4)
Power Supply Voltage 100 to 240 VAC 50/60 Hz (AC type) / 12 to 24 VDC (DC type)
Allowable Voltage Range AC 85 to 264 V / DC 10.8 to 28.8 V
Power Consumption CPU unit: 5–11 VA (AC) / 2–5 W (DC); Expansion: 2–4 VA
Inrush Current 4.5 A max (AC) / 30 A max (DC)
Operating Temperature 0 to 55°C (LCD type) / -25 to 55°C (LED type)
Storage Temperature -20 to 75°C (LCD type) / -40 to 75°C (LED type)
Operating Humidity 10 to 90% RH (no condensation)
Mounting Surface mounting or 35 mm DIN rail
Protection Structure IP20 (panel-mounted)
Dielectric Strength AC 2,300 V for 1 min (between power / I/O / output terminals)
Vibration Resistance IEC 60068-2-6: 5–9 Hz 3.5 mm amplitude, 9–150 Hz 9.8 m/s²
Shock Resistance IEC 60068-2-27: 147 m/s² X/Y/Z, 3 times each
Program Backup Built-in EEP-ROM (optional memory cassette)
Max Count Speed 150 Hz (8-digit counter, DC type only)
Safety Standards cUL US, UL 508, CSA C22.2 No.142, EN/IEC 61131-2
EMC CISPR 11 Group 1 Class A
Weight 10-point CPU: approx. 300 g / 20-point CPU: approx. 350 g / Expansion: approx. 120 g
Model note: ZENL1121 is an Omron ZEN series component. The ZEN series is obsolete — Omron ended orders in March 2024; reference data above is compiled from Omron official datasheets (fa.omron.co.jp).

Compatibility & Cross-References

Designed for use within the Omron ZEN programmable relay system. Verify your ZEN CPU model and expansion configuration before ordering.

Applications

  • Small-scale machine control and automation
  • Timing, counting and relay logic replacement
  • Legacy ZEN panel / machine maintenance and repair

Warranty & Shipping

  • Availability: Stock and condition vary; contact us for real-time stock status and tested condition.
  • Inspection & testing: each unit is visually inspected and functionally checked before packing.
  • Delivery: orders are processed within 2-4 business days after payment confirmation; standard worldwide delivery about 5-8 business days, express available, free shipping over $500.

Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.

Independent supplier: Omron part ZENL1121 is supplied by SHLY-PLC, an independent industrial automation distributor. Brand names and part numbers are used for product identification and remain the property of their respective owners; this listing is not affiliated with, sponsored or endorsed by the manufacturer.
