IFM KN0001 Capacitive Sensor
IFM KN0001 Capacitive Sensor

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

IFM

IFM KN0001 Capacitive Sensor

SKU: KN0001
(0)
$392.04
Available
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056
electronic  |  Capacitive sensor

KN0001

KN0001 manufacturer technical specifications

Key Ratings at a Glance

Output function
normally open / closed; (selectable)
Sensing range[mm]
Programmable sensing range
Housing
Threaded type
Dimensions[mm]
M30 x 1.5 / L = 105
Special feature
optical setting aid
Installation
detection through non-metallic container walls
Media
dry bulk material; liquids
Medium temperature[°C]
-25...100

Electrical — Power & Input

Operating voltage[V] 30...250 AC
Max. voltage drop switching output AC[V] 10
Minimum load current[mA] 5
Max. leakage current[mA] 2.5 (250 V) / 1.7 (110 V)
Permanent current rating of switching output AC[mA] 150; (200 (...40 °C))
Short-time current rating of switching output[mA] 1000; (20 ms / 0,5 Hz)

Outputs & Signals

Output function normally open / closed; (selectable)
Max. voltage drop switching output AC[V] 10
Permanent current rating of switching output AC[mA] 150; (200 (...40 °C))
Short-time current rating of switching output[mA] 1000; (20 ms / 0,5 Hz)
Switching frequency AC[Hz] 5
Switching status 1 x LED, yellow

Features & Performance

Sensing range[mm] Programmable sensing range
Housing Threaded type
Frequency AC[Hz] 47...63
Protection class I
Switching frequency AC[Hz] 5
Sensing range adjustable yes
Protection IP 67
Mounting non-flush mountable

Mechanical & Environmental

Dimensions[mm] M30 x 1.5 / L = 105
Medium temperature[°C] -25...100
Ambient temperature[°C] -25...80

Compliance, Approvals & Standards

Product approvals CE, UKCA, UL/cUL, RoHS
EMC EN 61000-6-x / EN 55011 (industrial environment)
Safety standard IEC/EN 61131 / 61800 / 60947 (product-specific)
