Schneider Electric BMXSAI0410 | Sensor & Transducer

BMXSAI0410 Schneider Electric - Modicon X80 Safety Analog Input Module - 4 Channels 4-20mA. Modicon X80 safety analog input module with 4 isolated channels supporting 4-20mA current input. Features 16-bit A/D conversion, second order digital filtering, and channel-to-channel isolation. Designed for safety-critical automation applications requiring high-precision analog signal acquisition.

• Brand: Schneider Electric
• Category: PLC I/O Module
• Series: Modicon X80
• Product Type: Safety analog input module
• Number of Inputs: 4
• Input Type: Current 4-20 mA (high level)
• Input Isolation: Isolated between channels
• A/D Conversion: 16 bits
• Input Resolution: 13 bits (0-12500 counts)
• Input Impedance: 286 Ohm
• Permitted Overload: 25 mA
• Measurement Error: <= 0.3% of full scale (4-20 mA, 25-60 degrees C)
• Temperature Drift: 30 ppm/degrees C
• Filter Type: Second order digital filtering
• Nominal Read Cycle Time: 6 ms for 4 channels
• Crosstalk Attenuation: 120 dB
• Isolation Voltage: 500 V DC between channels, 1500 V DC to ground/bus
• Measurement Resolution: 2 microA (4-20 mA)
• MTBF Reliability: 463,000 hours
• Current Consumption: 200 mA at 3.3 V DC, 115 mA at 24 V DC
• Protection Rating: IP20
• Operating Temperature: 0 to 60 degrees C
• Operating Altitude: 0-2000 m (up to 5000 m with derating)
• Status LEDs: RUN (green), ERR (red), I/O (red), 1 per channel (green)
• Electrical Connection: 20-way connector
• Standards: EN/IEC 61131-2, CE, UL, CSA, EAC

Designed for safety-critical industrial automation systems using Modicon M580 PLCs. Suitable for high-precision analog signal acquisition in process control, energy monitoring, and safety instrumented systems where isolated 4-20mA current loop inputs are required.
