The Beckhoff EP2328-0002 is an ethercat box (4-channel digital input + 4-channel digital output, 24 V DC, 3 ms, 2 A, M12). It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.
Technical parameters compiled from the manufacturer data sheet and reference documentation.
| Technical Specifications | |
| I/O & Signals | |
| Number of channels | 4 inputs + 4 outputs |
| Input/output connections | M12 x 1, 5-pin, a-coded |
| Input filter | typ. 3 ms |
| Signal voltage “0” | -3…+5 V |
| Signal voltage “1” | 11…30 V, 6 mA input current (EN 61131-2, type 3) |
| Sensor supply | from control voltage, max. 0.5 A, short-circuit proof in total |
| Load type | resistive, inductive, lamp load |
| Max. output current | 2 A per channel, individually short-circuit proof, ∑ 4 A |
| Switching times | typ. T ON : 200 µs, typ. T OFF : 200 µs |
| Power & Current | |
| Rated load voltage | 24 V DC (-15%/+20%) |
| Short-circuit current | typ. 15 A |
| Auxiliary power current | typ. 20 mA |
| Current consumption from U S | typ. 120 mA |
| Power supply connection | feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, A-coded |
| Communication | |
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, 4-pin, A-coded, shielded |
| Distributed clocks | – |
| Mechanical & Environmental | |
| Weight | approx. 165 g |
| Operating temperature | -25…+60°C |
| Storage temperature | -40…+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals & Compliance | |
| Specification | EN 61131-2, type 1/3 |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx, cFMus |
| Ex marking | ATEX: II 3G Ex ec IIC T4 Gc II 3D Ex tc IIIC T135°C Dc IECEx: Ex ec IIC T4 Gc Ex tc IIIC T135°C Dc cFMus: Class I, II, III, Division 2, Groups A, B, C, D, F and G Class I, Zone 2, AEx ec IIC T4 Gc Zone 22, AEx tc IIIC T135°C Dc |
| General | |
| Electrical isolation | 500 V |
Model variants, options and firmware revisions can affect fitment. Before ordering the Beckhoff EP2328-0002 ethercat box, share your existing part number or project requirements and our team will cross-reference comparable in-stock Beckhoff units and verify compatibility. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for identification only.
