The B&R X20BM36 is a bus base. bus module, for X20 SafeIO modules, with node number switch, internal I/O power supply connected through. The listed technical data is based on the manufacturer's data sheet. It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.
Technical parameters compiled from the manufacturer data sheet and reference documentation.
| Technical Specifications | |
| General | |
| Bus module | Bus module, for X20 SafeIO modules, with node number switch, internal I/O power supply connected through |
| Power consumption | |
| Bus | 0.13 W |
| Internal I/O | - |
| Certifications | |
| CE | Yes |
| UKCA | Yes |
| CRA (Cyber Resilience Act) | In preparation |
| ATEX | Zone 2, II 3G Ex nA nC IIA T5 Gc IP20, Ta (see X20 user's manual) FTZÚ 09 ATEX 0083X |
| UL | cULus E115267 Industrial control equipment |
| HazLoc | cCSAus 244665 Process control equipment for hazardous locations Class I, Division 2, Groups ABCD, T5 |
| DNV | In preparation |
| KC | Yes |
| Additional power dissipation caused by actuators (resistive) [W] | - |
| Nominal voltage | 24 VDC |
| Permissible contact load | 10 A |
| Mounting orientation | |
| Horizontal | Yes |
| Vertical | Yes |
| Installation elevation above sea level | 0 to 2000 m, no limitation |
| Degree of protection per EN 60529 | IP20 |
| Operation | |
| Horizontal mounting orientation | -25 to 60°C |
| Vertical mounting orientation | -25 to 50°C |
| Derating | - |
| Storage | -40 to 85°C |
| Transport | -40 to 85°C |
| Relative humidity | |
| Operation | 5 to 95%, non-condensing |
| Storage | 5 to 95%, non-condensing |
| Transport | 5 to 95%, non-condensing |
| Pitch | 25 +0.2 mm |
| Automation Studio HW Upgrades | Version (Date) |
| V4.0 HW Upgrade (X20BM36) | 1.1.0.0 (08/18/2021) 1.0.0.6 (05/27/2019) 1.0.0.1 (02/25/2013) |
| Certificates | Version (Date) |
| 2226379 CSA Certificate of Compliance X20 X67 | 2026_09 (09/21/2026) |
| E115267 UL Certificate of Compliance X20 | 2026_08_27 (08/27/2026) |
| E537419 UL Certificate of Compliance X20 | 2026-07 (07/27/2026) |
| EU_Declaration_of_Conformity_X20_FuctionalSafety | 2026_09 (09/21/2026) |
| TAA00000BJ DNV Type Approval Certificate X20 | 13.0 (05/04/2026) 12.0 (02/18/2026) 11.0 (02/27/2024) |
| X20, X67 KC certificates | 2.00 (08/17/2026) |
| Documentation | Version (Date) |
| Data sheet X20(c)BMxx - Legacy | 1.141 (05/03/2019) - DE 1.141 (05/03/2019) - EN |
| Data sheet X20(c)BMxx - mapp Safety | 2.14 (12/16/2022) - DE 2.14 (12/16/2022) - EN |
| X20 System User´s Manual | 4.40 (03/10/2026) - DE 4.40 (03/12/2026) - IT 4.40 (03/12/2026) - FR 4.40 (03/10/2026) - EN |
| E-CAD (Electro or EPLAN Templates) | Version (Date) |
| X20 EPLAN P8 from V2.4 | 4.0.5 (08/31/2023) 4.0.4 (10/27/2022) |
| M-CAD (Mechan. Templates) | Version (Date) |
| 3D file STEP X20BMxx | 1.00 (05/07/2013) |
| DFX File Bus module | 1.00 (05/27/2013) |
| Dimensions PDF X20 Bus module | 1.00 (05/27/2013) |
Model variants, options and firmware revisions can affect fitment. Before ordering the B&R X20BM36 bus base, share your existing part number or project requirements and our team will cross-reference comparable in-stock B&R units and verify compatibility. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for identification only.
