B&R 8BAC0122.000-1 Power Supply

SKU: 8BAC0122.000-1
(0)
$863.57
Available
Condition
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056

8BAC0122.000-1 Industrial Automation Component | B&R

The B&R 8BAC0122.000-1 is a industrial automation component. The listed technical data is based on the manufacturer's data sheet. It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.

Features

  • Module type: ACOPOSmulti plug-in module.
  • Input voltage: Resolver transformation ratio: 0.5 ±10%.
  • Max. power consumption: 1 W.
  • Resolution @ ü = 0.5: Number of pole pairs * 22600.
  • CE: Yes.
  • UKCA: Yes.

Specifications

Technical parameters compiled from the manufacturer data sheet and reference documentation.

Technical Specifications
Certifications
CE Yes
UKCA Yes
CRA (Cyber Resilience Act) In preparation
UL cULus E225616 Power conversion equipment
KC Yes
Module type ACOPOSmulti plug-in module
B&R ID code 0x20B6
Slot Slots 1 and 2
Max. power consumption 1 W
Electrical isolation
Encoder - ACOPOSmulti No
Module-side connection 9-pin male DSUB connector
Status indicators UP/DN LEDs
Encoder monitoring Yes
Max. encoder cable length 100 m
Protective measures
Overload-proof Yes
Short-circuit proof Yes
Output voltage Typ. 3 V eff
Output current Max. 50 mA eff
Frequency 10 kHz
Resolution @ ü = 0.5 Number of pole pairs * 22600
Digital converter resolution 14-bit
Input impedance 10.4 kΩ - j 11.1 kΩ
Input voltage Resolver transformation ratio: 0.5 ±10%
Common-mode voltage Max. ±20 V
Signal transmission Differential signals
Operation
Nominal 5 to 40°C
Maximum 55°C
Storage -25 to 55°C
Transport -25 to 70°C
Relative humidity
Operation 5 to 85%
Storage 5 to 95%
Transport Max. 95% at 40°C
8BCR0025.1111A-0 ACOPOSmulti resolver cable, length 25 m, 3x 2x 24 AWG (19x 0.127), 12-pin female speedtec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8BCR0020.1111A-0 ACOPOSmulti resolver cable, length 20 m, 3x 2x 24 AWG (19x 0.127), 12-pin female speedtec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8BCR0015.1111A-0 ACOPOSmulti resolver cable, length 15 m, 3x 2x 24 AWG (19x 0.127), 12-pin female speedtec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8BCR0010.1111A-0 ACOPOSmulti resolver cable, length 10 m, 3x 2x 24 AWG (19x 0.127), 12-pin female speedtec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8BCR0007.1111A-0 ACOPOSmulti resolver cable, length 7 m, 3x 2x 24 AWG (19x 0.127), 12-pin female speedtec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8BCR0005.1111A-0 ACOPOSmulti resolver cable, length 5 m, 3x 2x 24 AWG (19x 0.127), 12-pin female speedtec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
Automation Studio HW Upgrades Version (Date)
V4.0 HW Upgrade (8BAC0122.000-1) 2.2.0.0 (09/01/2017)
V6.0 HW Upgrade (8BAC0122.000-1) 3.0.1.0 (04/22/2026) 3.0.0.0 (07/02/2024)
Certificates Version (Date)
ACOPOSmulti KC certificates 1.10 (03/18/2024)
E225616 UL Certificate of Compliance ACOPOSmulti (UL 508C) 1.30 (07/20/2022)
E225616 UL Certificate of Compliance ACOPOSmulti (UL 61800-5-1) 2.10 (07/20/2022)
EU Declaration Servos ACOPOSmulti 2026-06 (06/30/2026)
UK Declaration Servos ACOPOSmulti 2026-06 (06/29/2026)
Documentation Version (Date)
ACOPOSmulti User´s Manual 1.30 (08/18/2025) - DE 1.30 (08/18/2025) - EN 1.20 (10/09/2023) - DE 1.20 (12/05/2024) - IT 1.20 (12/05/2024) - FR 1.20 (10/09/2023) - EN
Datasheet 8BAC0122.000-1 1.6 (09/20/2018) - DE 1.6 (11/09/2018) - EN
E-CAD (Electro or EPLAN Templates) Version (Date)
ACOPOSmulti EPLAN P8 from V2.4 4.0.1 (12/18/2020)

Compatibility & Cross-References

Model variants, options and firmware revisions can affect fitment. Before ordering the B&R 8BAC0122.000-1 industrial automation component, share your existing part number or project requirements and our team will cross-reference comparable in-stock B&R units and verify compatibility. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for identification only.

Applications

  • Automation control and signal handling in industrial machinery.
  • Integration into new and existing control architectures.
  • Maintenance, spares and retrofit of installed equipment.
  • Machine and line-level use across manufacturing and process industries.

Warranty

  • Availability: 8BAC0122.000-1 is stocked for prompt shipment; contact us for current quantity and lead time.
  • Inspection & testing: each unit is visually inspected and functionally checked before packing.
  • Delivery: orders are processed within 2-4 business days after payment confirmation; standard worldwide delivery is about 5-8 business days, express shipping is available, and orders over $500 ship free.

    • Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.

Independent supplier: B&R part 8BAC0122.000-1 is supplied by SHLY-PLC, an independent industrial-automation distributor. Brand names and part numbers are used for product identification and remain the property of their respective owners; this listing is not affiliated with, sponsored or endorsed by the manufacturer.
