B&R 8AC122-60-2 Connection Cable

SKU: 8AC122-60-2
(0)
$1,082.58
Available
Condition
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056

8AC122-60-2 Industrial Automation Component | B&R

The B&R 8AC122-60-2 is a industrial automation component. The listed technical data is based on the manufacturer's data sheet. It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.

Features

  • Module type: ACOPOS plug-in module.
  • Type: BRX.
  • Input voltage: 3 to 7 V rms.
  • Power consumption: Max. 2.5 W.
  • Angular position resolution: 14 bits/rev.
  • CE: Yes.

Specifications

Technical parameters compiled from the manufacturer data sheet and reference documentation.

Technical Specifications
Certifications
CE Yes
UKCA Yes
CRA (Cyber Resilience Act) Non-compliant
UL cULus E225616 Power conversion equipment
KC Yes
Module type ACOPOS plug-in module
B&R ID code 0xA48B
Slot Slots 2, 3 and 4
Max. cable length 100 m
Power consumption Max. 2.5 W
Reference output
Output current Max. 50 mA eff
Differential voltage Typ. 3.4 V eff
Frequency 10 kHz
Signal transmission Differential signals
Electrical isolation
Resolver - ACOPOS No
Resolver
Input frequency 10 kHz
Input voltage 3 to 7 V rms
Number of pins 2-pin
Type BRX
Max. phase shift ±45°
Max. elec. angular error ±10 angular minutes
Nominal transformation ratio 0.5 ±10%
Sine/Cosine inputs
Input impedance at 10 kHz (per pin) 10.4 kΩ - j 11.1 kΩ
Encoder-ACOPOS electrical isolation No, common-mode voltage on the sine/cosine inputs max. ±20 V
Angular position resolution 14 bits/rev
Module-side connection 9-pin female DSUB
Status indicators UP/DN LEDs
Bandwidth 2.5 kHz
Encoder monitoring Yes
Accuracy ±8 angular minutes
Operation
Nominal 5 to 40°C
Maximum 55°C
Storage -25 to 55°C
Transport -25 to 70°C
Relative humidity
Operation 5 to 85%
Storage 5 to 95%
Transport Max. 95% at 40°C
8CR025.12-1 Resolver cable, length 25 m, 3x 2x 24 AWG (19x 0.127), 12-pin female Intercontec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8CR020.12-1 Resolver cable, length 20 m, 3x 2x 24 AWG (19x 0.127), 12-pin female Intercontec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8CR015.12-1 Resolver cable, length 15 m, 3x 2x 24 AWG (19x 0.127), 12-pin female Intercontec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8CR010.12-1 Resolver cable, length 10 m, 3x 2x 24 AWG (19x 0.127), 12-pin female Intercontec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8CR007.12-1 Resolver cable, length 7 m, 3x 2x 24 AWG (19x 0.127), 12-pin female Intercontec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
8CR005.12-1 Resolver cable, length 5 m, 3x 2x 24 AWG (19x 0.127), 12-pin female Intercontec resolver connector, 9-pin male DSUB servo connector, can be used in cable drag chains
Automation Studio HW Upgrades Version (Date)
V2.7 HW Upgrade (8AC122.60-3) 1.0.0.0 (10/13/2008)
V3.0 HW Upgrade (8AC122.60-3) 1.0.0.0 (10/13/2008)
V3.0 HW Upgrade (8AC122.60-3) 1.0.0.2 (06/10/2014)
V4.0 HW Upgrade (8AC122.60-3) 2.2.0.0 (09/01/2017)
V6.0 HW Upgrade (8AC122.60-3) 2.2.1.0 (04/22/2026) 2.2.0.0 (09/30/2024)
Certificates Version (Date)
ACOPOS KC certificates 1.00 (04/03/2019)
E225616 UL Certificate of Compliance ACOPOS 1.1 (09/11/2019)
EU Declaration Servos ACOPOS 2024-02 (10/29/2025)
UK Declaration Servos ACOPOS 2022-09 (09/08/2022)
Documentation Version (Date)
ACOPOS User´s Manual 2.10 (07/15/2020) - DE 2.10 (05/23/2022) - EN
Datasheet 8AC122.60-3 1.5 (04/24/2020) - DE 1.5 (04/24/2020) - EN
E-CAD (Electro or EPLAN Templates) Version (Date)
ACOPOS EPLAN P8 from V2.4 4.0.0 (09/26/2019)
M-CAD (Mechan. Templates) Version (Date)
3D file STEP 8AC122.60-x 1.0 (03/04/2013)

Compatibility & Cross-References

Model variants, options and firmware revisions can affect fitment. Before ordering the B&R 8AC122-60-2 industrial automation component, share your existing part number or project requirements and our team will cross-reference comparable in-stock B&R units and verify compatibility. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for identification only.

Applications

  • Automation control and signal handling in industrial machinery.
  • Integration into new and existing control architectures.
  • Maintenance, spares and retrofit of installed equipment.
  • Machine and line-level use across manufacturing and process industries.

Warranty

  • Availability: 8AC122-60-2 is stocked for prompt shipment; contact us for current quantity and lead time.
  • Inspection & testing: each unit is visually inspected and functionally checked before packing.
  • Delivery: orders are processed within 2-4 business days after payment confirmation; standard worldwide delivery is about 5-8 business days, express shipping is available, and orders over $500 ship free.

    • Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.

Independent supplier: B&R part 8AC122-60-2 is supplied by SHLY-PLC, an independent industrial-automation distributor. Brand names and part numbers are used for product identification and remain the property of their respective owners; this listing is not affiliated with, sponsored or endorsed by the manufacturer.

Frequently Asked Questions

Q: What condition is the 8AC122-60-2 supplied in?

A: Each unit is inspected and functionally checked before sale. Contact us for the current stock condition and quantity.

Q: How quickly can the 8AC122-60-2 ship?

A: Orders are processed within 2-4 business days after payment confirmation. Standard worldwide delivery is about 5-8 business days, express shipping is available and orders over $500 ship free.

Q: Can you confirm compatibility or a replacement for the 8AC122-60-2?

A: Yes. Share your existing part number or application and our technical team will verify compatibility and provide cross-references to comparable in-stock models.
