The B&R 3CP360-60-1 is a industrial automation component. 1x RS232, 1x Ethernet, 1x USB. The listed technical data is based on the manufacturer's data sheet. It is supplied by SHLY-PLC, an independent industrial-automation distributor: every unit is visually inspected and functionally checked before dispatch, held in ready stock and shipped worldwide for maintenance, spares and retrofit use. Share your application or existing part number and our team will confirm fitment and comparable in-stock alternatives.
Technical parameters compiled from the manufacturer data sheet and reference documentation.
| Technical Specifications | |
| General | |
| Interfaces | 1x RS232, 1x Ethernet, 1x USB |
| System module | CPU |
| CPU | Pentium 266 |
| Diagnostics | |
| Battery | Yes, using LED status indicator and software |
| CPU function | Yes, using LED status indicator |
| CompactFlash | Yes, using LED status indicator |
| Ethernet | Yes, using LED status indicator |
| Support | |
| ACOPOS support | Yes |
| Visual Components support | Yes |
| Power consumption | |
| 24 VDC | 3.0 W |
| 5 VDC | 11.0 W |
| Total | 14.0 W without memory card and without interface module |
| Electrical isolation | |
| IF1 - IF2 | Yes |
| IF1 - IF3 | No |
| IF2 - IF3 | Yes |
| PLC - IF1 | No |
| PLC - IF2 | Yes |
| PLC - IF3 | No |
| Certifications | |
| CE | Yes |
| UKCA | Yes |
| UL | cULus E115267 Industrial control equipment |
| Status indicators | CPU function, battery, CompactFlash, Ethernet |
| Processor | |
| L2 cache | 512 kB |
| Data buffering | |
| Battery monitoring | Yes |
| Lithium battery | At least 3 years |
| Standard memory | |
| RAM | 32 MB DRAM |
| User RAM | 496 kB SRAM |
| CompactFlash slot | 1 |
| L1 cache for data and program code | 2x 16 kB |
| Real-time clock | Nonvolatile, resolution 1 s |
| Insert slots | 1 for IF7xx aPCI interface modules |
| Floating point unit (FPU) | Yes |
| Integrated I/O processor | Processes I/O data points in the background |
| Reset button | Yes |
| Remanent variables | 256 kB |
| Shortest task class cycle time | 400 µs |
| Typical instruction cycle time | 0.02 µs |
| Interface IF1 | |
| Type | RS232 |
| Execution | 9-pin male DSUB connector |
| Max. transfer rate | 115.2 kbit/s |
| Interface IF2 | |
| Type | Ethernet |
| Execution | Shielded RJ45 port |
| Line length | Max. 100 m between two stations (segment length) |
| Transfer rate | 10/100 Mbit/s |
| Interface IF3 | |
| Type | USB 1.1 |
| Quantity | 1 |
| Execution | Type A |
| Degree of protection per EN 60529 | IP20 |
| Temperature | |
| Operation | 0 to 60°C |
| Storage | -25 to 60°C |
| Relative humidity | |
| Operation | 5 to 95% |
| Dimensions | |
| Width | System 2005 double-width |
| Slot | |
| Base unit | 3 + 4 |
| Expansion unit | No |
| Note | Order application memory (CompactFlash) separately, backup battery included in delivery |
| 0CFCRD.8192E.02 | CompactFlash 8 GB extended temp. |
| 0CFCRD.4096E.02 | CompactFlash 4096 MB extended temp. |
| 0CFCRD.2048E.02 | CompactFlash 2048 MB extended temp. |
| 0CFCRD.1024E.02 | CompactFlash 1024 MB extended temp. |
| 0CFCRD.0512E.02 | CompactFlash 512 MB extended temp. |
| 0CFCRD.016GE.02 | CompactFlash 16 GB extended temp. |
| 4A0006.00-000 | Lithium battery, 3 V / 950 mAh, button cell |
| 0AC201.91 | Lithium batteries 4 pcs., 3 V / 950 mAh button cell |
| Automation Studio HW Upgrades | Version (Date) |
| V4.0 HW Upgrade (3CP360.60-1) | 1.0.0.1 (09/16/2013) |
| Documentation | Version (Date) |
| Datasheet 3CP360.60-1 | 1.0 (06/08/2004) - DE 1.0 (01/14/2005) - FR 1.0 (06/08/2004) - EN |
Model variants, options and firmware revisions can affect fitment. Before ordering the B&R 3CP360-60-1 industrial automation component, share your existing part number or project requirements and our team will cross-reference comparable in-stock B&R units and verify compatibility. This listing is provided by an independent industrial-automation distributor; brand names and part numbers are used for identification only.
