Allen-Bradley · 2711R-T4T
2711R-T4T is an Allen-Bradley 2711R-T4T — PANELVIEW 800 4.3-INCH HMI TERMINAL. Official specification values published for this catalog number: Power Supply 24V DC；Certifications Australian RCM；Panel Cutout dimensions / (HxW) 99 x 119 mm / 3.9 x 4.7 in..
| Electrical | |
| category(1) / Wiring | 3 – on power ports / 2 – on communication ports |
|---|---|
| Wiring category(1) | 3 – on power ports |
| Input voltage range | 18…32V DC (24V DC nom) |
| Operator input | Analog touch and function keys |
| Power Consumption (max) | 9 W (0.39 A @ 24V DC) |
| Power Supply | 24V DC |
| Resolution (pixels) | 480 x 272 |
| Mechanical | |
| Panel Cutout dimensions / (HxW) | 99 x 119 mm / 3.9 x 4.7 in. |
| Enclosure type ratings | Meets NEMA/UL Type 4X (indoor) 12, 13, and IP65 |
| Dimensions (HxWxD), approx | 116 x 138 x 43 mm / 4.6 x 5.4 x 1.7 in. |
| Panel (HxW) Cutout dimensions | 99 3.9 x x 119 4.7 in. mm |
| Weight, approx | 0.333 kg (0.73 lb) |
| Environment and compliance | |
| Certifications | Australian RCM |
| North American temperature / code | T4A |
| Conducted RF immunity | IEC 61000-4-6: / 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz |
| EFT/B immunity | IEC 61000-4-4: / ±2 kV @ 5 kHz on power ports / ±1 kV @ 5 kHz on communication ports |
| ESD immunity | IEC 61000-4-2: / 4 kV contact discharges / 8 kV air discharges |
| Emissions | IEC 61000-6-4 |
| Radiated RF immunity | IEC 61000-4-3: |
| Relative humidity | IEC 60068-2-30 (Test Db, Unpackaged Damp Heat): / 5…95% noncondensing |
| Shock, nonoperating | IEC 60068-2-27 (Test Ea, Unpackaged Shock): / 30 g |
| Shock, operating | IEC 60068-2-27 (Test Ea, Unpackaged Shock): / 15 g |
| Surge transient immunity | IEC 61000-4-5: / ±500V line-line(DM) and ±500V line-earth(CM) on DC power ports / ±1 kV line-earth(CM) on communication ports |
| Temperature, nonoperating | IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold), / IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat), / IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock): / -25…70 °C (-13…158 °F) |
| Temperature, operating | IEC 60068-2-1 (Test Ad, Operating Cold), / IEC 60068-2-2 (Test Bd, Operating Dry Heat), / IEC 60068-2-14 (Test Nb, Operating Thermal Shock): / 0…50 °C (32…122 °F) |
| Temperature, surrounding air, max | 50 °C (122 °F) |
| Vibration | IEC 60068-2-6 (Test Fc, Operating):| / 2 g @ 10…500 Hz |
| North American temperature | T4A |
| General | |
| Heat dissipation / 2711R-T4T / 2711R-T7T / 2711R-T10T | 23 BTU/hr / 34 BTU/hr / 61 BTU/hr |
| China RoHS | SJ/T 11364-2014, GB/T 26572-2011, SJ/Z 11388-2009 |
| Backlight | LED |
| Backlight lifespan, min | 40,000 hours |
| Battery lifespan, min | 5 years @ 25 °C (77 °F) |
| Colors | 65K colors |
| Display area (WxH) | 95 x 53.9 mm (3.74 x 2.12 in.) |
| Display size | 4 in. |
| Display type | Color transmissive TFT active matrix LCD, widescreen format |
| Ethernet 10/100 Mbps | 1 |
| Flash Memory (ROM) min | 256 MB |
| Front Bezel Protection | IP65, NEMA 4X, 12, 13 |
| Memory card | USB port and micro-SD (Secure Digital) card – Industrial grade micro-SD cards recommended. Supports SDSC and Class 6 & Class 10 SDHC micro-SD cards, FAT32/16 / formats, up to 32 GB maximum size. |
| MicroSD slot | Yes |
| Operating System | WINCE 6.0 |
| Preferred controller | Micro800, MicroLogix |
| Processor, CPU speed | 800 MHz CPU |
| Programming port | Ethernet port |
| RS232/RS422/485 (isolated) | Separate RS-232 and RS422/RS485 connectors |
| Real-time clock with battery | Yes |
| Recipe | 50 recipe files |
| SDRAM (RAM) min | 256 MB DDR |
| Software | Connected Components Workbench software, release 8.0 and later |
| USB Host (USDB 2.0) | Yes |
| Not published by the manufacturer — 待原厂规格书核定 | |
| Supply voltage | 待原厂规格书核定 |
| I/O and communication | 待原厂规格书核定 |
| Mounting | 待原厂规格书核定 |
| Enclosure rating | 待原厂规格书核定 |
| Touch type | 待原厂规格书核定 |
| Operating temperature | 待原厂规格书核定 |
Values above are copied verbatim from the manufacturer product page (https://www.rockwellautomation.com/en-us/products/details.2711r-t4t.html) or the manufacturer technical data publication. Fields listed with the value 待原厂规格书核定 are not published by the manufacturer for this catalog number: the field name is kept, no value is estimated, and the original manufacturer data sheet is required before use.
Available from stock with datasheet, certificates and a quotation on request.
Q.What specification value does the manufacturer publish for 2711R-T4T?
For 2711R-T4T The manufacturer product page publishes certifications = Australian RCM. Confirm the revision of the installed unit if the catalog number has been superseded.
Q.What specification value does the manufacturer publish for 2711R-T4T?
For 2711R-T4T The official manufacturer data sheet publishes panel cutout dimensions / (hxw) = 99 x 119 mm / 3.9 x 4.7 in.. Confirm the revision of the installed unit if the catalog number has been superseded.
Q.What specification value does the manufacturer publish for 2711R-T4T?
For 2711R-T4T The official manufacturer data sheet publishes category(1) / wiring = 3 – on power ports / 2 – on communication ports. Confirm the revision of the installed unit if the catalog number has been superseded.
Q.What specification value does the manufacturer publish for 2711R-T4T?
For 2711R-T4T The official manufacturer data sheet publishes north american temperature / code = T4A. Confirm the revision of the installed unit if the catalog number has been superseded.
Q.How do I confirm compatibility of 2711R-T4T before ordering?
Match the catalog number 2711R-T4T and the specification values above against the nameplate of the installed unit, and confirm the firmware or hardware revision where a revision-sensitive part is involved.
