Allen-Bradley · PowerFlex 520 drive
25B-E022N104 is an Allen-Bradley variable-frequency drive with Rated operational voltage 1-phase 200-240 V / 3-phase 380-480 V; Overload capacity 150% for 60 s; Enclosure rating IP20 (IEC 60529). It is used in pump sets, conveyor belts, fan and compressor drives where the installed unit is matched to the original catalog number and a compact, documented part is required.
| Electrical | |
| Rated operational voltage | 1-phase 200-240 V / 3-phase 380-480 V |
|---|---|
| Supply voltage | 1-phase 200...240 V / 3-phase 380...480 V AC |
| Frequency | 50/60 Hz |
| Control method | V/f, sensorless vector (IEC 61800-2) |
| Overload capacity | 150% for 60 s |
| I/O and communication | |
| Communication ports | EtherNet/IP, DeviceNet |
| Mechanical | |
| Enclosure rating | IP20 (IEC 60529) |
| Environment and compliance | |
| Operating temperature | 0...+40 °C (IEC 60068-2-1) |
| Certifications | CE, UL, cULus |
Values follow the Allen-Bradley PowerFlex 520 drive specification for this catalog number; parameters not confirmed for this variant are omitted rather than estimated.
| Allen-Bradley PowerFlex 520 drive variants | |||
| Catalog number | Overload capacity | Rated operational voltage | Frequency |
|---|---|---|---|
| 25B-E022N104 (this page) | 150% for 60 s | 1-phase 200-240 V / 3-phase 380-480 V | 50/60 Hz |
| 25B-E012N104 | 150% for 60 s | 1-phase 200-240 V / 3-phase 380-480 V | 50/60 Hz |
| 25B-E019N104 | 150% for 60 s | 1-phase 200-240 V / 3-phase 380-480 V | 50/60 Hz |
| 25B-E032N104 | 150% for 60 s | 1-phase 200-240 V / 3-phase 380-480 V | 50/60 Hz |
All variants share the same PowerFlex 520 drive footprint and terminal layout; the columns above show where they differ. Selecting a different catalog number changes the electrical interface, not the mounting.
The 25B-E022N104 is the device-level element in an Allen-Bradley variable-frequency drive installation. It receives the field signals and control supply listed above — 1-phase 200...240 V / 3-phase 380...480 V AC — and switches or conditions the load within the 1-phase 200-240 V / 3-phase 380-480 V ratings shown in the Specifications table. Wiring and protective devices are sized to those same numbers, not to a generic assumption.
Typical installations place it in pump sets, conveyor belts, fan and compressor drives, where the unit is matched to the original catalog number and the enclosure provides standard panel or DIN-rail support. Record the catalog number and revision from the nameplate of the installed unit before specifying a like-for-like spare.
Q.What supply does this device require?
It requires 1-phase 200...240 V / 3-phase 380...480 V AC. Size the supply source to the same rating shown in the Specifications table.
Q.What are the key electrical ratings?
The confirmed ratings include 1-phase 200-240 V / 3-phase 380-480 V and CE, UL, cULus marking. Cross-check them against the installed unit's nameplate.
Q.What is the operating temperature range?
The confirmed operating range is 0...+40 °C (IEC 60068-2-1). Panels running beyond it need derated sizing.
Q.What replaces a unit that is no longer in production?
For a like-for-like spare, record the catalog number and revision from the nameplate; a current-production equivalent is identified by matching function and ratings.
