Allen-Bradley · PowerFlex 4 drive
22C-D030N103 is an Allen-Bradley variable-frequency drive with Rated operational voltage 3-phase 400 V AC; Overload capacity 150 % for 60 s (IEC 61800-2); Enclosure rating IP20 (IEC 60529). It is used in pump sets, conveyor belts, fan and compressor drives where the installed unit is matched to the original catalog number and a compact, documented part is required.
| Electrical | |
| Rated operational voltage | 3-phase 400 V AC |
|---|---|
| Supply voltage | 1-phase 200...240 V / 3-phase 380...480 V AC |
| Input voltage range | 480V AC |
| Output current | 30 A |
| Frequency | 50/60 Hz (IEC 61800-2) |
| Control method | V/f, sensorless vector (IEC 61800-2) |
| Overload capacity | 150 % for 60 s (IEC 61800-2) |
| I/O and communication | |
| Communication ports | EtherNet/IP, DeviceNet |
| Mechanical | |
| Mounting | Cabinet / DIN rail |
| Enclosure rating | IP20 (IEC 60529) |
| Environment and compliance | |
| Operating temperature | 0...+40 °C (IEC 60068-2-1) |
| Certifications | CE, UL, cULus |
Values follow the Allen-Bradley PowerFlex 4 drive specification for this catalog number; parameters not confirmed for this variant are omitted rather than estimated.
| Allen-Bradley PowerFlex 4 drive variants | |||
| Catalog number | Overload capacity | Rated operational voltage | Frequency |
|---|---|---|---|
| 22C-D030N103 (this page) | 150 % for 60 s (IEC 61800-2) | 3-phase 400 V AC | 50/60 Hz (IEC 61800-2) |
| 22C-D038A103 | 150 % for 60 s (IEC 61800-2) | 3-phase 400 V AC | 50/60 Hz (IEC 61800-2) |
| 22C-D010N103 | 150% for 60 s | 1-phase 200-240 V / 3-phase 380-480 V | 50/60 Hz |
| 22C-D012N103 | 150% for 60 s | 1-phase 200-240 V / 3-phase 380-480 V | 50/60 Hz |
All variants share the same PowerFlex 4 drive footprint and terminal layout; the columns above show where they differ. Selecting a different catalog number changes the electrical interface, not the mounting.
The 22C-D030N103 is the device-level element in an Allen-Bradley variable-frequency drive installation. It receives the field signals and control supply listed above — 1-phase 200...240 V / 3-phase 380...480 V AC — and switches or conditions the load within the 3-phase 400 V AC ratings shown in the Specifications table. Wiring and protective devices are sized to those same numbers, not to a generic assumption.
Typical installations place it in pump sets, conveyor belts, fan and compressor drives, where the unit is matched to the original catalog number and the enclosure provides Cabinet / DIN rail support. Record the catalog number and revision from the nameplate of the installed unit before specifying a like-for-like spare.
Allen-Bradley 22C-D030N103 — Variable frequency drive for motor speed and torque control in pumps, fans, conveyors and general industrial machinery. The figures below are taken from the specification table on this page for catalog number 22C-D030N103; confirm the installed unit's part number and revision so the replacement matches both electrically and mechanically.
Available from stock with datasheet, certificates and a quotation on request.
Q.Before ordering 22C-D030N103, which overload capacity entry should be checked?
The overload capacity entry quoted above is 150 % for 60 s (IEC 61800-2). Confirm this figure against the unit currently in the panel.
Q.Where can I find the input voltage range data for 22C-D030N103?
It is listed in the specification table for Allen-Bradley 22C-D030N103 as 480V AC. Use the value as the reference when sourcing a current-production equivalent.
Q.For 22C-D030N103, what does the specification table state about control method?
The specification table lists control method = V/f, sensorless vector (IEC 61800-2) for Allen-Bradley 22C-D030N103. Check the revision of the installed unit if the catalog number has been superseded.
Q.Can the 22C-D030N103 replace the unit currently installed in my panel?
Compare catalog number 22C-D030N103 and the ratings above with the nameplate of the installed device. A current-production equivalent is selected by function and electrical rating, not by the label alone.
Q.How do I confirm compatibility of 22C-D030N103 before ordering?
Match the catalog number 22C-D030N103 and the specification values listed above against the installed unit, then confirm the firmware or hardware revision where a revision-sensitive part is involved.
