| Model Number | V18345-1010121001 |
| Product Series | V18345 |
| Product Type | Electro-Pneumatic Positioner |
| Action Type | Direct acting (DA) |
| Input Signal | 4-20 mA (HART compatible) |
| Supply Pressure Range | 1.4 - 6 bar |
| Air Consumption | ≤ 3.6 Nl/min (at 6 bar) |
| Linearity | ≤ ± 0.5% |
| Hysteresis | ≤ 0.3% |
| Ambient Temperature | -40°C to +80°C |
| Vibration Resistance | IEC 60068-2-6 (10-150 Hz) |
| Enclosure Rating | IP66 / IP67 (NEMA 4X) |
| Communication | HART Protocol |
| Certifications | ATEX, FM, CSA |
| Housing Material | Aluminum alloy / Ss |
| Weight | Approx. 2.5 kg |
Independent industrial automation supplier · SHLY-PLC
All specifications subject to manufacturer's standard terms and conditions.
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | V18345-1010121001 |
| series | TZIDC (V18345) |
| acting | Single-acting (Y1 output only) |
| input_signal | 4-20 mA, two-wire |
| communication | HART |
| supply_pressure | 1.4 ... 7 bar (20 ... 100 psi) typical |
| mounting | Linear actuators per IEC 60531/NAMUR or rotary per VDI/VDE 3845 |
| enclosure | Aluminum, anodized/varnished, NEMA 4X / IP66 |
| indication | LCD local indicator + operator panel |
| configuration | Easysetup automatic calibration |
Source: datasheet / product page
