| Model Number | TF65-28 |
| Product Series | AF/TF Thermal Overload Relay |
| Product Type | Bimetallic Thermal Overload Relay |
| Current Setting Range | 22 - 32 A |
| Trip Class | Class 10A per IEC 60947-4-1 |
| Auxiliary Contacts | 1× NC + 1× NO |
| Reset Type | Auto / Manual reset |
| Temperature Compensation | -25°C to +60°C |
| Rated Operational Voltage | 690 V AC |
| Frequency | 50/60 Hz |
| Mounting | Direct mount on contactor / DIN Rail |
| Standards | IEC 60947-4-1 |
| Dimensions | 45 × 86 × 73 mm |
| Protection Class | IP20 |
Independent industrial automation supplier · SHLY-PLC
All specifications subject to manufacturer's standard terms and conditions.
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | TF65-28 |
| order_code | 1SAZ811201R1001 |
| setting_range | 22 ... 28 A |
| rated_operational_current_Ie | 28 A |
| trip_class | Class 10 |
| number_of_poles | 3P |
| auxiliary_contacts | 1 NC (trip) + 1 NO (signal) |
| rated_insulation_voltage_Ui | 690 V |
| rated_operational_voltage_main | 690 V AC / 440 V DC |
| rated_impulse_withstand_voltage_Uimp | 8 kV (main) / 6 kV (aux) |
| reset | Automatic or manual selectable |
| features | Temperature compensation, trip-free mechanism, STOP function, trip indication |
| mounting | Directly mounted on AF40/AF52/AF65 contactors |
| operating_temperature | -40 ... +70 C |
| protection_degree | Housing IP20 |
Source: datasheet / product page
