ABB S802PV-S16 Miniature Circuit Breaker
ABB S802PV-S16 Miniature Circuit Breaker

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

ABB

ABB S802PV-S16 Miniature Circuit Breaker

SKU: S802PV-S16
(0)
$99.04
Available
Condition
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056
ABB | S800 PV MCB

S802PV-S16

S800 Series PV — 2-Pole PV MCB Curve S

Key Ratings at a Glance

Poles
2
Rated Current
16 A
Curve S
Breaking Cap.
36 kA
@ 500V DC
Voltage
1000V
DC

Technical Specifications

Parameter Value
Catalog Number S802PV-S16
Product Series S800 Series PV
Number of Poles 2
Rated Current (In) 16 A
Tripping Characteristic Curve S (1.5-2x In)
Short-Circuit Breaking Capacity (Icn) 36 kA
Rated Voltage 500/1000 V DC
Rated Frequency DC
Mounting DIN rail (TH35)
Degree of Protection IP20
Operating Temperature -25 °C ... +55 °C
Standard IEC/EN 60947-2
Application Solar/PV DC protection

Applications & Features

  • Solar PV string protection
  • DC distribution boards
  • Photovoltaic systems up to 1000V DC
  • Battery storage systems
  • Industrial DC power distribution

Compliance & Approvals

CE | UL | CSA | IEC/EN 60947 | RoHS Compliant
— SHLY-PLC Industrial Automation Supplier

Frequently Asked Questions

Q: What is the warranty for ABB S802PV-S16?

Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.

Q: How fast can you ship S802PV-S16?

A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).

Q: Is S802PV-S16 compatible with ABB systems?

A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.

Model Specifications

converted_model S802PV-S16
series S800PV-S
number_of_poles 2P
rated_current_In 16 A
tripping_characteristic SP (PV-specific)
rated_voltage_Ue up to 1500 V DC
rated_short_circuit_capacity 5 kA (DC)
product_id 2CCF019601R0001 (S802PV-SP16)
standard IEC 60947-2 Annex P

Source: datasheet / product page

Standard International (tracked courier): delivered in 5–8 business days. In-stock items are processed within 2–4 business days. USD 25 flat rate on orders of $500 or less; free on orders over $500.

Express (DHL Express / FedEx International): upgraded expedited delivery in 2–4 business days. The Express surcharge is calculated at checkout based on destination and order weight.

Non-Stock / On-Order items ship on request: dispatch time is confirmed before your order — see our Shipping Policy. Remote-area and overweight surcharges, where applicable, are shown before checkout.

Every product is covered by a 12-month seller warranty provided by SHLY-PLC, effective from the date of delivery, against defects in materials and workmanship under normal use. Manufacturer or factory warranty service is not applicable, and extended warranty packages are not provided.

This warranty does not cover damage from misuse, improper installation, power surges, neglect, unauthorized repair, or normal wear and tear. See our Return Policy for warranty-claim instructions.
★★★★★

No reviews yet. Be the first to review this product!
