ABB JCU-11 Junction Control Unit
ABB JCU-11 Junction Control Unit

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

ABB

ABB JCU-11 Junction Control Unit

SKU: JCU-11
(0)
$481.49
Available
Condition
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056
ABB ACS850 Drive System

JCU-11

Junction Control Unit — ACS850 Drive System

Type
Junction Control Unit
Series
ACS850
Technical Specifications
Product Type Junction Control Unit
Model JCU-11
Order Code (SKU) JCU-11
Type Junction Control Unit
Application ACS850 Drive Systems

Key Features

  • Control unit for ACS850 medium voltage drives
  • Junction interface for power modules
  • Integrated protection and monitoring
  • Modular design for easy maintenance

Typical Applications

  • Medium voltage motor control
  • Industrial process drives
  • Mining applications

Compliance & Approvals

CE, IEC

Worldwide Shipping

Frequently Asked Questions

Q: What is the warranty for ABB JCU-11?

Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.

Q: How fast can you ship JCU-11?

A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).

Q: Is JCU-11 compatible with ABB systems?

A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.

Model Specifications

converted_model JCU-11
part_number 3AUA0000047068
power_supply 24 VDC (+/-10%), 1.6 A, supplied from drive power unit or external supply via XPOW
digital_inputs 6x DI + 1x start interlock DIIL, 24 VDC
digital_I_O 2x DI/O configurable as pulse train in/out, max 32 kHz
relay_outputs 3x RO (RO1...RO3), max 250 VAC / 30 VDC, 2 A
analog_inputs 2x AI, voltage or current
analog_outputs 2x AO, current
thermistor_input motor PTC thermistor
weight approx. 0.58 kg
note Plug-in control unit for ACS850-04 drive modules (160-560 kW); not a DCS control unit

Source: datasheet / product page
