ACS880 Industrial Drive | Wall-Mounted | 380-415 | 110.0 kW | Frame R9
| Parameter | Value |
|---|---|
| Product Series | ACS880 Single Drive |
| Product Type | Wall-Mounted Drive (ACS880-01) |
| Input Voltage | 380-415 V, 3-phase, 47.5-63 Hz |
| Output Voltage | 0 to input voltage, 3-phase |
| Output Frequency | 0 to 500 Hz |
| Rated Output Current (IN) | 293.0 A |
| Maximum Output Current | 362.0 A |
| Rated Power (PN) | 110.0 kW |
| Light Overload Current (ILd) | 278.0 A / 110.0 kW |
| Heavy Duty Current (IHD) | 210.0 A / 90.0 kW |
| Frame Size | R9 |
| Protection Class | IP21 (NEMA Type 1) |
| Motor Control | Direct Torque Control (DTC) |
| Power Factor | cos φ = 0.98 (fundamental) |
| Noise Level | 68 dB(A) |
| Heat Dissipation | 3300 W |
| Cooling Airflow | 550 m³/h |
| Dimensions (H×W×D) | 955x380x413 mm |
| Weight | 98 kg |
| Ambient Temperature | -15°C to +55°C |
| Max Altitude | 4000 m |
| Analog I/O | 2 AI / 2 AO |
| Digital I/O | 6 DI / 2 DO |
| Communication | Modbus RTU, PROFINET, PROFIBUS, EtherNet/IP, CANopen |
| USB Port | 1 |
| Braking Chopper | Built-in (R5-R9 with option) |
| Safe Torque Off (STO) | Standard |
| Coated Boards | Standard |
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | ACS880-01-430A-3 |
| rated_voltage | 380...415 V, 3-phase |
| rated_current_IN_A | 430 |
| typical_motor_power_kW | 250 |
| frame_size | R9 |
| enclosure | IP21 standard (IP55 option) |
| mounting | Wall-mounted |
| control | Direct torque control (DTC) |
Source: datasheet / product page
