The ABB Terra AC W7-G5-R-0 (6AGC082155) is a single-phase 7.4 kW AC electric vehicle charging wallbox equipped with a 5-meter Type 2 tethered cable and integrated RFID authentication. Designed for residential and light commercial charging, it offers
| Parameter | Value |
|---|---|
| Product ID | 6AGC082155 |
| ABB Type | TAC-W7-G5-R-0 (Terra AC W7) |
| Product Category | EV Charging Station / AC Wallbox |
| Charging Mode | Mode 3, Level 2 |
| Output Power | 7.4 kW |
| Output Current | 32 A |
| Electrical Phase | Single-phase |
| Input/Output Voltage | 220–240 V AC, 50/60 Hz |
| Connector Type | Type 2 tethered cable, 5 m |
| Authentication | RFID, ChargerSync app |
| Communication Protocols | OCPP 1.6J, Modbus RTU RS-485 |
| Connectivity | WiFi, Ethernet (RJ45), Bluetooth |
| Protection | Overcurrent, overvoltage, undervoltage, ground fault (DC residual current), surge protection (Category III) |
| Energy Metering | Revenue grade, Class B (±1%) |
| IP/IK Rating | IP54, IK10 |
| Mounting | Wall mount |
| Dimensions (H × W × D) | 320 × 195 × 110 mm |
| Net Weight | Approx. 5 kg (with cable) |
| Operating Temperature | -35 to +50 °C (derating may apply) |
| Storage Temperature | -40 to +80 °C |
| Operating Altitude | Up to 2000 m |
| Standards | IEC 61851-1, IEC 61851-23, IEC 62955, EN 61000-6-2, EN 61000-6-3, CE |
| Country of Origin | China |
Designed for industrial automation and control applications. Provides reliable signal processing and system coordination.
This product carries the following certifications and approvals:
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Estimated delivery: 5-8 business days to the United States and Canada. Express options available at checkout.
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 6AGC082155 |
| extended_type | TAC-W7-G5-R-0 |
| output_power | 7.4 kW |
| phases | Single-phase |
| rated_current | 32 A |
| connector | Type 2, attached cable 5 m |
| access_control | RFID |
| alternative_ref | 3Q510001800A |
Source: datasheet / product page
Standard International (tracked courier): delivered in 5–8 business days. In-stock items are processed within 2–4 business days. USD 25 flat rate on orders of $500 or less; free on orders over $500.
Express (DHL Express / FedEx International): upgraded expedited delivery in 2–4 business days. The Express surcharge is calculated at checkout based on destination and order weight.
Non-Stock / On-Order items ship on request: dispatch time is confirmed before your order — see our Shipping Policy. Remote-area and overweight surcharges, where applicable, are shown before checkout.
Every product is covered by a 12-month seller warranty provided by SHLY-PLC, effective from the date of delivery, against defects in materials and workmanship under normal use. Manufacturer or factory warranty service is not applicable, and extended warranty packages are not provided.
This warranty does not cover damage from misuse, improper installation, power surges, neglect, unauthorized repair, or normal wear and tear. See our Return Policy for warranty-claim instructions.
