The ABB Terra AC W22-S-R-C-0 (6AGC082154) is a 22 kW three-phase AC electric vehicle charging wallbox with a Type 2 front socket featuring a safety shutter, integrated RFID authentication, and 4G cellular connectivity. Part of ABB's Terra AC series,
| Parameter | Value |
|---|---|
| Product ID | 6AGC082154 |
| ABB Type | TAC-W22-S-R-C-0 (Terra AC W22) |
| Product Category | EV Charging Station / AC Wallbox |
| Charging Mode | Mode 3, Level 2 |
| Output Power | 22 kW |
| Output Current | 32 A |
| Electrical Phase | Three-phase (3P+N+PE) |
| Input/Output Voltage | 320–480 V AC, 50/60 Hz |
| Connector Type | Type 2 front socket with shutter |
| Number of Sockets | 1 |
| Authentication | RFID, ChargerSync app, free vending |
| Communication Protocols | OCPP 1.6J, Modbus RTU RS-485, Modbus TCP/IP |
| Connectivity | WiFi, Ethernet (RJ45), Bluetooth, 4G (LTE/WCDMA) |
| Protection | Overcurrent, overvoltage, undervoltage, ground fault (DC residual current), surge protection (Category III) |
| Energy Metering | Revenue grade, Class B (±1%) |
| IP/IK Rating | IP54, IK10 |
| Mounting | Wall mount |
| Dimensions (H × W × D) | 320 × 195 × 110 mm |
| Operating Temperature | -35 to +50 °C (derating may apply) |
| Storage Temperature | -40 to +80 °C |
| Operating Altitude | Up to 2000 m |
| Standards | IEC 61851-1, IEC 61851-23, IEC 62955, EN 61000-6-2, EN 61000-6-3, CE |
| Country of Origin | China |
Designed for industrial automation and control applications. Provides reliable signal processing and system coordination.
This product carries the following certifications and approvals:
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Estimated delivery: 5-8 business days to the United States and Canada. Express options available at checkout.
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 6AGC082154 |
| extended_type | TAC-W22-S-R-C-0 |
| output_power | 22 kW |
| phases | 3-phase |
| rated_current | 32 A |
| output_voltage | 320-480 V AC |
| connector | Type 2 socket (no cable) |
| access_control | RFID |
Source: datasheet / product page
