The ABB Terra AC W22-T-0 (6AGC081279) is a 22 kW three-phase AC electric vehicle charging wallbox from ABB's Terra AC series. Designed for residential and commercial charging applications, it features a Type 2 socket outlet, integrated surge protecti
| Parameter | Value |
|---|---|
| Product ID | 6AGC081279 |
| ABB Type | TAC-W22-T-0 (Terra AC W22) |
| Product Category | EV Charging Station / AC Wallbox |
| Charging Mode | Mode 3, Level 2 |
| Output Power | 22 kW |
| Output Current | 32 A |
| Electrical Phase | Three-phase (3P+N+PE) |
| Input/Output Voltage | 320–480 V AC, 50/60 Hz |
| Connector Type | Type 2 socket (front socket without shutter) |
| Number of Sockets | 1 |
| Protection | Overcurrent, overvoltage, undervoltage, ground fault (DC residual current), integrated surge protection (Overvoltage Category III) |
| Energy Metering | Revenue grade, Class B (±1%) |
| Communication Protocols | OCPP 1.6J, Modbus RTU RS-485, Modbus TCP/IP |
| Connectivity | WiFi, Ethernet (RJ45), Bluetooth Low Energy 5.0 |
| User Authentication | ABB RFID card, ChargerSync app/portal |
| Status Indication | 5 LEDs (power / connectivity / authorization / charging / error) |
| IP/IK Rating | IP54, IK10 |
| Mounting | Wall mount |
| Dimensions (H × W × D) | 320 × 195 × 110 mm |
| Operating Temperature | -35 to +50 °C (derating may apply) |
| Storage Temperature | -40 to +80 °C |
| Operating Altitude | Up to 2000 m |
| Standards | IEC 61851-1, IEC 61851-23, IEC 62955, EN 61000-6-2, EN 61000-6-3, CE |
| Country of Origin | China |
Designed for industrial automation and control applications. Provides reliable signal processing and system coordination.
This product carries the following certifications and approvals:
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Estimated delivery: 5-8 business days to the United States and Canada. Express options available at checkout.
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 6AGC081279 |
| extended_type | TAC-W22-T-0 |
| output_power | 22 kW |
| phases | 3-phase |
| rated_current | 32 A |
| output_voltage | 320-415 V AC |
| connector | Type 2 socket outlet |
| protection_rating | IP54 |
Source: datasheet / product page
