The ABB DS201 C32 AC30 is a 1P+N DIN-rail mounted RCBO providing combined overload, short-circuit, and earth leakage protection. Rated at 32 A with 30 mA residual current sensitivity, C characteristic, and Type AC fault detection.
| Parameter | Value |
|---|---|
| Parameter | Value |
| Manufacturer Part Number | 2CSR256140R1324 |
| Model | DS201 C32 AC30 |
| Product Type | RCBO (Residual Current Circuit Breaker with Overcurrent Protection) |
| Number of Poles | 1P+N |
| Protected Poles | 1 |
| Rated Current (In) | 32 A |
| Rated Residual Current (IΔn) | 30 mA |
| Tripping Characteristic | C |
| Type of Residual Current | Type AC |
| Rated Voltage (Ur) | 230 V AC |
| Rated Operational Voltage | 240 V AC (IEC 60898-1) |
| Rated Frequency | 50/60 Hz |
| Rated Short-Circuit Capacity (Icn) | 6 kA |
| Rated Residual Breaking Capacity (IΔm) | 1 kA (30 mA), 3 kA (300 mA) |
| Operating Characteristic | Instantaneous |
| Tripping Mechanism | Thermal (overload) / Electromagnetic (short circuit) |
| Power Loss (Total) | 4.5 W |
| Electrical Endurance | 10,000 cycles |
| Mechanical Endurance | 20,000 cycles |
| Protection Degree | IP20 (housing), IP40 (with cover) |
| Terminal Type | Cylinder-lift bi-directional (screw) |
| Connecting Capacity (Cable) | 1 - 25 mm² |
| Connecting Capacity (Busbar) | Up to 10 mm² |
| Tightening Torque | 2.8 Nm |
| Mounting | DIN Rail (TH35-7.5) |
| Power Supply Connection | Arbitrary (top or bottom) |
| Contact Position Indicator (CPI) | Red ON / Green OFF |
| Earth Fault Indicator | Blue flag on toggle |
| Test Pushbutton | Yes |
| Neutral Terminal Position | Right |
| Accessories Available | Yes |
| Operating Temperature | -25 °C to +55 °C |
| Storage Temperature | -40 °C to +70 °C |
| Modules | 2 |
| Dimensions (W x H x D) | 35 x 85 x 69 mm |
| Standards | IEC/EN 61009-1, IEC/EN 61009-2-1 |
| RoHS Compliant | Yes |
Provides critical protection for electrical circuits against overload, short circuit, and earth leakage faults.
This product carries the following certifications and approvals:
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Estimated delivery: 5-8 business days to the United States and Canada. Express options available at checkout.
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 2CSR256140R1324 |
| series | DS203NC (System Pro M Compact) |
| poles | 3P+N (4P total) |
| trip_curve | C |
| rated_current | 32 A |
| residual_current | 30 mA |
| rcd_type | Type A |
| breaking_capacity | 6 kA |
| rated_voltage | 400 V~ |
Source: datasheet / product page
