ABB F204 A S-40/0.3 residual current circuit breaker from the F200 series provides reliable protection against fault current to earth for people and installations. Selective (S-type) version with time-delayed tripping for upstream protection coordination.
| Parameter | Value |
|---|---|
| Product Series | F200 |
| Model | F204 A S-40/0.3 |
| Number of Poles | 4P |
| Rated Current (In) | 40 A |
| Rated Residual Current | 300 mA |
| Type of Residual Current | A type |
| Rated Operational Voltage | 230/400 V AC |
| Rated Insulation Voltage (Ui) | 500 V |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Rated Conditional Short-Circuit Current (Inc) | 10 kA |
| Rated Frequency | 50-60 Hz |
| Operating Characteristic | Selective (S-type) |
| Electrical Endurance | 10,000 cycles |
| Position of Neutral Terminals | Right |
| Mounting Type | DIN-Rail |
| Degree of Protection | IP2X |
| Ambient Temperature | -25 to 55 °C |
| Width | 70 mm (4 modules) |
| Height | 85 mm |
| Depth | 69 mm |
| Net Weight | 360 g |
| Standards | IEC/EN 61008 |
| Certifications | CE, RoHS |
Ships via DHL / FedEx / UPS.. Bulk inquiry welcome.
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Estimated delivery: 5-8 business days to the United States and Canada. Express options available at checkout.
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 2CSF204201R3400 |
| abb_type | F204AS-40/0.3 |
| poles | 4P |
| rated_current | 40 A |
| rated_residual_current | 300 mA |
| rcd_type | Type A, selective (S) |
| rated_voltage | 480Y/277 V AC |
Source: datasheet / product page
