The S202-C10 is a two-pole miniature circuit breaker from the ABB System pro M compact S200 range, providing combined overload and short-circuit protection for single- and two-phase circuits. S200 MCBs are the established standard for final-circuit protection in industrial, commercial and residential distribution.
Fitted with a C-trip characteristic and rated at 10 A, this breaker is intended for general mixed resistive/inductive loads. The magnetic trip level of the C curve makes it suitable for circuits with moderate inrush currents such as lighting groups, small motors and control circuits.
The device occupies two DIN modules and features box terminals with finger-safe protection, a padlockable toggle actuator with clear ON/OFF position indication, and DIN-rail snap mounting for rapid panel assembly.
| Brand / Series | ABB System pro M compact / S200 |
| Product Type | Miniature Circuit Breaker (MCB) |
| Catalog Designation | S202-C10 |
| Order Code | 2CDS272001R0101 |
| Rated Current In | 10 A |
| Number of Poles | 2P |
| Trip Characteristic | C (5-10 In magnetic trip) |
| Rated Voltage Ue | 400 V AC |
| Rated Frequency | 50/60 Hz |
| Rated Short-Circuit Breaking Capacity Icn | 6 kA (230/400 V AC) |
| Rated Impulse Withstand Voltage Uimp | 6.2 kV at sea level |
| Standards | IEC/EN 60898-1; UL1077 (CSA C22.2 No.235) |
| Terminal Type | Box terminals, finger-safe |
| Connection Cross Section | Flexible 0.75-25 mm² / Rigid 1-35 mm² |
| Tightening Torque | 2.5 N·m |
| Mounting | 35 mm DIN rail |
| Mechanical Endurance | 20,000 switching cycles |
| Electrical Endurance | 10,000 switching cycles |
| Ambient Operating Temperature | -25 to +55 °C |
| Degree of Protection | IP40 (housing) / IP20 (terminals) |
| Product Net Weight | 0.244 kg |
| Brand | ABB |
| Condition | New Surplus |
| Warranty | (provided by us) |
Shipping & Warranty: Fast order processing with worldwide delivery available. This item is sold as New Surplus Contact our team for compatibility checks, bulk pricing, or spare-parts sourcing support.
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Estimated delivery: 5-8 business days to the United States and Canada. Express options available at checkout.
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 2CDS272001R0101 |
| series | S200M |
| model_name | S202M-D10 |
| poles | 2P |
| tripping_curve | D |
| rated_current | 10 A |
| breaking_capacity | 10 kA (Icu, 400 V AC, IEC/EN 60947-2) |
| rated_voltage | 440 V AC / 125 V DC |
| standard | IEC/EN 60947-2 |
| mounting | DIN rail |
Source: datasheet / product page
