1SVR730841R1500
Measuring & Monitoring Relays| Part Number | 1SVR730841R1500 |
| Manufacturer | ABB |
| Product Line Type | Single-Phase Current and Voltage Monitors |
| Product Main Type | CM-SRS |
| Function | Over- or undercurrent monitoring |
| Output | 2 c/o (SPDT) contacts |
| Rated Control Supply Voltage | 220 ... 240 V AC |
| Measuring Range | 0.3 ... 1.5 A1 ... 5 A3 ... 15 A |
| Time Range | 0 s or 0.1 ... 30 s tripping delay (ON) |
| Terminal Type | Screw Terminals |
| Ambient Air Temperature | Operation -20 ... +60 °CStorage -40 ... +85 °C |
| Product Net Width | 22.5 mm |
| Product Net Height | 85.6 mm |
| Product Net Depth / Length | 103.7 mm |
| Product Net Weight | 0.181 kg |
| Maximum Operating Voltage UL/CSA | Output Circuit 300 V AC |
| Contact Rating UL/CSA | B300 |
| RoHS Status | Following EU Directive 2011/65/EU |
| Connecting Capacity UL/CSA | Flexible 1x 18-14 AWGFlexible 2x 18-16AWGRigid 1x 20-12 AWGRigid 2x 20-14 AWG |
| Tightening Torque UL/CSA | 7.08 in·lb |
| ETIM 4 | EC001440 - Current monitoring relay |
| ETIM 5.0 | EC001440 - Current monitoring relay |
| ETIM 6.0 | EC001440 - Current monitoring relay |
| ETIM 7 | EC001440 - Current monitoring relay |
| eClass | 7.0 27371802 |
| Package Level 1 Units | 1 piece |
| Package Level 1 Width | 97 mm |
| Package Level 1 Height | 109 mm |
| Package Level 1 Depth / Length | 30 mm |
| Package Level 1 Gross Weight | 0.203 kg |
| Package Level 1 EAN | 4016779852357 |
| Minimum Order Quantity | 1 |
| Customs Tariff Number | 85364900 |
| ECCN | N |
| ECN | N |
| ABB Business Unit | ELSP - Smart Power |
| ABB Product Group | 3099>>ELSP |
| Environmental product declaration | 1SAC200438H0001 |
| Condition | New — ABB Product |
Monitor critical parameters in manufacturing and process control systems for optimal performance and safety.
Ensure reliable power supply monitoring in switchgear panels and electrical distribution boards.
Integrate with BMS systems for energy monitoring, HVAC control, and facility management.
Protect sensitive equipment from voltage anomalies, phase failures, and power quality issues.
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
Standard International (tracked courier): delivered in 5–8 business days. In-stock items are processed within 2–4 business days. USD 25 flat rate on orders of $500 or less; free on orders over $500.
Express (DHL Express / FedEx International): upgraded expedited delivery in 2–4 business days. The Express surcharge is calculated at checkout based on destination and order weight.
Non-Stock / On-Order items ship on request: dispatch time is confirmed before your order — see our Shipping Policy. Remote-area and overweight surcharges, where applicable, are shown before checkout.
Every product is covered by a 12-month seller warranty provided by SHLY-PLC, effective from the date of delivery, against defects in materials and workmanship under normal use.
This warranty does not cover damage from misuse, improper installation, power surges, neglect, unauthorized repair, or normal wear and tear. See our Return Policy for warranty-claim instructions.
