The ABB 1SVR405613R8100 (CR-M125DC4L) is a pluggable miniature interface relay from the CR-M series. Operating at 125V DC coil voltage with 4 c/o (4PDT) output rated at 250V / 6A. Provides electrical isolation between PLC/controller outputs and the sensor/actuator level. Features an integrated test button for manual actuation and compact pluggable design for quick installation. Compatible with ABB CR-M standard and logical sockets, and pluggable function modules.
| Parameter | Value |
|---|---|
| Product Type | ABB CR-M125DC4L |
| Catalog Number | 1SVR405613R8100 |
| Product Family | Pluggable Interface Relay |
| Rated Coil Voltage | 125 V DC |
| Output Configuration | 4 c/o (4PDT) |
| Rated Contact Current | 6 A |
| Rated Operational Voltage | 250 V AC |
| Contact Material | AgNi (Silver-Nickel) |
| Min. Switching Voltage | 5 V |
| Min. Switching Current | 5 mA (AgNi) |
| Insulation Voltage | 250 V AC |
| Dielectric Strength | 2500 V AC (coil-contacts) |
| Mechanical Life | ≥ 20 × 10⁶ operations |
| Electrical Life (AC-1) | ≥ 10⁵ operations |
| Response Time (Pick-up) | ≤ 13 ms (DC) / ≤ 10 ms (AC) |
| Response Time (Drop-out) | ≤ 3 ms (DC) / ≤ 8 ms (AC) |
| Max. Switching Frequency | 18000 ops/h (no load) |
| Width on DIN Rail | 21.2 mm |
| Net Weight | 0.033 kg |
| Operating Temperature | -40 ... +70 °C |
| Storage Temperature | -40 ... +85 °C |
| Max. Operating Altitude | 2000 m |
| Degree of Protection | IP40 (relay) / IP20 (terminals) |
| Mounting | DIN Rail (EN 60715) / Socket Mount |
Isolate PLC outputs from field wiring, protecting expensive controllers
Match voltage levels between control and power circuits
Switch motors, solenoids, and indicator lights from control signals
Distributed I/O in manufacturing, packaging, and material handling
