3-Pole Moulded Case Circuit Breaker — 50 kA Breaking Capacity at 415V AC
| Parameter | Value |
|---|---|
| Product Type | Moulded Case Circuit Breaker |
| Frame Size | XT3 |
| Trip Unit | TMD |
| Rated Current (In) | 200 A |
| Number of Poles | 3 |
| Rated Voltage (Ur) | 690 V AC / 500 V DC |
| Rated Insulation Voltage (Ui) | 800 V (XT1/XT2) / 1000 V (XT3) |
| Rated Impulse Withstand (Uimp) | 8 kV |
| Ics @ 220V AC | 100 kA |
| Ics @ 380-415V AC | 50 kA |
| Ics @ 440V AC | 25 kA |
| Ics @ 690V AC | 7 kA |
| Frequency | 50/60 Hz |
| Connection | Front / Bolt |
| Dimensions (W×D×H) | 114 × 103 × 205 mm |
| Weight | 3.2 kg |
| Mounting | DIN Rail / Panel |
| Degree of Protection | IP20 |
| Standards | IEC/EN 60947-2 |
| CE Marking | Yes — Low Voltage Directive 2014/35/EU |
| RoHS | Compliant — Directive 2011/65/EU |
| UL/cUL | Listed (applicable standards) |
| IEC Standards | IEC/EN 60947 series |
| Marine Approvals | ABS, DNV, LR, BV, RINA (where applicable) |
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 1SDA068165R1 |
| family | SACE Tmax XT2 |
| extended_product_type | XT2H 160 BREAKING PART 3p F F |
| frame_current_Iu_A | 160 |
| breaking_class | H (70kA@415V) |
| number_of_poles | 3 |
| mounting | Fixed, front terminals |
| note | Breaking part only (cassette), no trip unit included |
Source: datasheet / product page
