3-Pole Moulded Case Circuit Breaker — 36 kA Breaking Capacity at 415V AC
| Parameter | Value |
|---|---|
| Product Type | Moulded Case Circuit Breaker |
| Frame Size | XT1N |
| Trip Unit | TMD |
| Rated Current (In) | 125 A |
| Number of Poles | 3 |
| Rated Voltage (Ur) | 690 V AC / 500 V DC |
| Rated Insulation Voltage (Ui) | 800 V (XT1/XT2) / 1000 V (XT3) |
| Rated Impulse Withstand (Uimp) | 8 kV |
| Ics @ 220V AC | 72 kA |
| Ics @ 380-415V AC | 36 kA |
| Ics @ 440V AC | 18 kA |
| Ics @ 690V AC | 5 kA |
| Frequency | 50/60 Hz |
| Connection | Front / Bolt |
| Dimensions (W×D×H) | 76.2 × 70 × 130 mm |
| Weight | 1.1 kg |
| Mounting | DIN Rail / Panel |
| Degree of Protection | IP20 |
| Standards | IEC/EN 60947-2 |
| CE Marking | Yes — Low Voltage Directive 2014/35/EU |
| RoHS | Compliant — Directive 2011/65/EU |
| UL/cUL | Listed (applicable standards) |
| IEC Standards | IEC/EN 60947 series |
| Marine Approvals | ABS, DNV, LR, BV, RINA (where applicable) |
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 1SDA067415R1 |
| product_family | SACE Tmax XT |
| frame | XT1N |
| rated_current_in_a | 80 |
| frame_rated_current_iu_a | 160 |
| trip_unit | TMD (thermomagnetic, fixed) |
| trip_setting | 80 - 800 |
| poles | 3 |
| version | Fixed with front terminals (F F) |
| breaking_class | N (Icu 36 kA @ 415 V) |
Source: datasheet / product page
