| Electrical Durability | 1500 cycle |
| Mechanical Durability | Nr. Operations 8500 cycle |
| Opening Time | CB with SOR 15 ms; CB with UVR 15 ms |
| Power Loss | at Rated Operating Conditions per Pole 8 W |
| Rated Current (In) | Main Circuit 100 A |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Insulation Voltage (Ui) | 690 V |
| Rated Operational Voltage | 550 V AC; 250 V DC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (240 V AC) 50 kA; (380 V AC) 18 kA; (415 V AC) 7.5 kA; (440 V AC) 6.25 kA; (480 V AC) 4.5 kA; (500 V AC) 2.5 kA; (250 V DC) 2 Poles in Series 5 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (240 V AC) 100 kA; (380 V AC) 36 kA; (415 V AC) 36 kA; (440 V AC) 25 kA; (480 V AC) 18 kA; (500 V AC) 10 kA; (250 V DC) 10 kA |
| Rated Uninterrupted Current (Iu) | 125 A |
| Release | TMF |
| Release Type | TM |
| Short-Circuit Performance Level | N |
| Sub-type | A1 |
| Terminal Connection Type | Front |
Standards: IEC
CE Declaration: 9AKK106713A5519
Data Sheet: 1SDC210032D0204
Product Main Type: SACE FORMULA
Product Class: SACE Tmax T
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 1SDA066731R1 |
| series | SACE Formula |
| extended_product_type | A1N 125 TMF 100-1000 3P F F IEC |
| trip_unit | TMF (fixed thermal-magnetic) |
| rated_current | 100 A |
| frame_size | 125 A |
| number_of_poles | 3 |
| breaking_capacity | 25 kA |
| mounting | Fixed, front terminals |
| alternate_catalog_no | AAN100TW |
| standards | IEC |
Source: datasheet / product page
